Wilkerson X01-04-000 - Manual

INSTALLATION
1. Refer to Warnings and Cautions.
2. Install unit in a vertical position.
3. Piping to this unit should be taken from the bottom of the air line, sump,
reservoir, or pneumatic device to be drained.
4. A drain line with 1/8-inch NPT connection may be attached to drain port,
if desired. Drain line should be 1/4-inch tubing size or larger, as short as
possible, and have no crimps in it. Too much restriction can hinder
draining action.
5. Maximum pressure rating is 150 psig (10.3 bar) for transparent plastic
bowls, and 200 psig (13.8 bar) for metal bowls. Temperature range is
32°F to 125°F (0°C to 52°C) for transparent plastic bowls, and 32°F to
150°F (0°C to 65.5°C) for metal bowls.
MAINTENANCE
1. Each time the bowl is cleaned:
a. Depressurize unit.
b. Inspect bowl seat and replace crazed, cracked, damaged or
deteriorated seal with original manufacturer's approved bowl seal.
2. DO NOT PRESSURIZE UNIT unless the bowl and bowl guard are in
position and the clamp ring is locked in place.
3. If automatic bowl drain fails to function properly, refer to Repair Kit
Installation Sheet 83-522-000 for repair instructions.
REPAIR KITS AND REPLACEMENT PARTS
Automatic Drain Assembly .................................................... XRP-96-244
Plastic Bowl w/Drain Seat and Bowl Guard .......................... XRP-95-746
Metal Bowl w/Drain Seat ........................................................ FRP-95-630
Bowl O-Ring Kit .................................................................... GRP-95-256
Bowl Guard for Plastic Bowl .................................................. GRP-95-808
Repair Kit .............................................................................. DRP-95-141
Drain Seat Assembly ............................................................ GRP-96-002
Richland, MI 49083 Tel: (269) 629-5000
Installation & Service Instructions
84-001-000
Drain Model X01 with
Variations and Accessories
ISSUED: February, 2005
Supersedes: February, 2004
Doc.# 84-001-000, Rev. 2
WARNING
FAILURE OR IMPROPER SELECTION OR IMPROPER USE OF THE
PRODUCTS AND/OR SYSTEMS DESCRIBED HEREIN OR RELATED ITEMS
CAN CAUSE DEATH, PERSONAL INJURY AND PROPERTY DAMAGE.
This document and other information from The Company, its subsidiaries
and authorized distributors provide product and/or system options for further
investigation by users having technical expertise. It is important that you
analyze all aspects of your application, including consequences of any failure
and review the information concerning the product or systems in the current
product catalog. Due to the variety of operating conditions and applications
for these products or systems, the user, through its own analysis and testing,
is solely responsible for making the final selection of the products and
systems and assuring that all performance, safety and warning requirements
of the application are met.
The products described herein, including without limitation, product features,
specifications, designs, availability and pricing, are subject to change by The
Company and its subsidiaries at any time without notice.
EXTRA COPIES OF THESE INSTRUCTIONS ARE AVAILABLE FOR INCLUSION
IN EQUIPMENT / MAINTENANCE MANUALS THAT UTILIZE THESE
PRODUCTS. CONTACT YOUR LOCAL REPRESENTATIVE.
!
WARNING
To avoid unpredictable system behavior that can cause personal injury
and property damage:
• Disconnect electrical supply (when necessary) before installation,
servicing, or conversion.
• Disconnect air supply and depressurize all air lines connected to
this product before installation, servicing, or conversion.
• Operate within the manufacturer’s specified pressure, temperature,
and other conditions listed in these instructions.
• Medium must be moisture-free if ambient temperature is below
freezing.
• Service according to procedures listed in these instructions.
• Installation, service, and conversion of these products must be
performed by knowledgeable personnel who understand how
pneumatic products are to be applied.
• After installation, servicing, or conversion, air and electrical supplies
(when necessary) should be connected and the product tested for
proper function and leakage. If audible leakage is present, or the
product does not operate properly, do not put into use.
• Warnings and specifications on the product should not be covered
by paint, etc. If masking is not possible, contact your local
representative for replacement labels.
!
! CAUTION
Polycarbonate bowls, being transparent and tough, are ideal for use with
Filters and Lubricators. They are suitable for use in normal industrial
environments, but should not be located in areas where they could be
subjected to direct sunlight, an impact blow, nor temperatures outside of the
rated range. As with most plastics, some chemicals can cause damage.
Polycarbonate bowls should not be exposed to chlorinated hydrocarbons,
ketones, esters and certain alcohols. They should not be used in air systems
where compressors are lubricated with fire-resistant fluids such as phosphate
ester and di-ester types.
Metal bowls are recommended where ambient and/or media conditions are
not compatible with polycarbonate bowls. Metal bowls resist the action of
most such solvents, but should not be used where strong acids or bases are
present or in salt laden atmospheres. Consult the factory for specific
recommendations where these conditions exist.
TO CLEAN POLYCARBONATE BOWLS USE MILD SOAP AND WATER
ONLY! DO NOT use cleansing agents such as acetone, benzene, carbon
tetrachloride, gasoline, toluene, etc., which are damaging to this plastic.
Bowl guards are recommended for added protection of polycarbonate bowls
where chemical attack may occur.
E N G L I S H
F R E N C H
AVERTISSEMENT
Afin d’éviter un fonctionnement imprévu du système pouvant
occasionner des blessures aux personnes et des dommages matériels :
• Débrancher l’alimentation électrique (si nécessaire) avant toute
installation, entretien ou conversion.
• Débrancher l’alimentation en air et dépressuriser toutes les
canalisations d’air connectées à cet appareil avant installation,
entretien ou conversion.
• Utiliser l’appareil conformément aux normes de pression,
température, et autres conditions spécifiées par le fabricant dans
ces instructions.
• Le médium doit être exempt d’humidité si la température descend
en dessous de 0°C.
• L’entretien doit se faire conformément aux procédures décrites ici.
• L’installation, l’entretien, et la conversion de ces appareils doivent
être effectués par des personnels qualifiés, au fait des techniques
pneumatiques.
• Après installation, entretien, ou conversion, les alimentations en air
et en électricité (si nécessaire) seront connectées et l’appareil testé
pour vérifier son fonctionnement correct et l’absence de fuites. Si
l’appareil présente une fuite audible ou ne fonctionne pas
correctement, ne pas l’utiliser.
• Les inscriptions concernant les avertissements et spécifications sur
l’appareil ne devront pas être recouvertes de peinture, etc. Si le
masquage est impossible, contactez votre représentant local pour
des étiquettes de remplacement.
!
FICHE D’INSTALLATION ET D’ENTRETIEN
Dispositif de vidange modèle X01 avec variations
et accessoires
