Wilkerson B28A - Manual

INSTALLATION
1. Refer to WARNINGS and CAUTIONS prior to installation.
2. Install as close to the point of use as possible.
3. Unit must be installed with the flow in the direction of the flow arrow on
the body cover and with bowl down.
4. Avoid using reducing bushings, couplings, etc., whenever possible
to install this product. These devices restrict air flow and can affect
performance.
5. Install filter/regulator in a vertical position with bowl side down.
6.
Maximum pressure rating is 150 psig (10.3 bar) for transparent
plastic bowls, and 250 psig (17.2 bar) for metal bowls. Temperature
range is 32°F to 125°F (0°C to 52°C) for transparent plastic bowls,
and 32°F to 150°F (0°C to 65.5°C) for metal bowls.
7. This product is supplied with two auxiliary ports located on the front and
rear faces of the body. These ports may be used as additional filtered/
regulated ports or for pressure gauges. A pipe plug is supplied to block
the unused port. Make sure pipe plug is sealed before installation.
8. To increase regulated pressure, pull adjusting knob up and turn
clockwise. To reduce pressure, turn knob counterclockwise. To lock
knob, push down.
9. To panel mount this unit the following applies:
– Model B18: Panel clearance hole diameter = 1.94" (49.3 mm).
– Model B18: Panel thickness 3/16" (4.8 mm) Max.
– Model B28: Panel clearance hole diameter = 2.44" (61.9 mm).
– Model B28: Panel thickness 3/16" (4.8 mm) to drain stem.
10. To install a drain line, use the following procedure:
– On units with the MANUAL DRAIN, attach flexible tubing having an
I.D. of 3/16" (4.8 mm) to drain stem.
– On units with the AUTOMATIC FLOAT DRAIN, install using a 3/8 or
10mm flexibile tubing.
MAINTENANCE
DEPRESSURIZE SYSTEM BEFORE
ATTEMPTING SERVICE!
THIS UNIT MAY BE SERVICED WITHOUT REMOVING THE
UNIT FROM THE COMPRESSED AIR LINE. UNIT SHOULD
BE SERVICED AT LEAST EVERY SIX MONTHS.
NOTE: The B28 and B28A (series A) have different internal parts and
require the use of different repair kits. The B28A is current design and
production began in December 1997. For identification purposes, the
Bonnet of the B28 has “28A” permanently marked in two places on the
!
Richland, MI 49083 Tel: (269) 629-5000
Installation & Service Instructions
84-014-000
Filter / Regulator Models B18, B28
and B28A
ISSUED: September, 2006
Supersedes: February, 2006
Doc. #84014000, ECN# 060870, Rev. 4
Bowl guards are recommended for added protection of polycarbonate bowls
where chemical attack may occasionally occur.
!
WARNING
To avoid polycarbonate bowl rupture that can cause personal injury or
property damage, do not exceed bowl pressure or temperature ratings.
Polycarbonate bowls have a 150 PSIG pressure rating and a maximum
temperature rating of 125°F.
WARNING
To avoid unpredictable system behavior that can cause personal injury
and property damage:
• Disconnect electrical supply (when necessary) before installation,
servicing, or conversion.
• Disconnect air supply and depressurize all air lines connected to this
product before installation, servicing, or conversion.
• Operate within the manufacturer’s specified pressure, temperature,
and other conditions listed in these instructions.
• Medium must be moisture-free if ambient temperature is below
freezing.
• Service according to procedures listed in these instructions.
• Installation, service, and conversion of these products must be
performed by knowledgeable personnel who understand how
pneumatic products are to be applied.
• After installation, servicing, or conversion, air and electrical supplies
(when necessary) should be connected and the product tested for
proper function and leakage. If audible leakage is present, or the
product does not operate properly, do not put into use.
• Warnings and specifications on the product should not be covered by
paint, etc. If masking is not possible, contact your local representative
for replacement labels.
WARNING
FAILURE OR IMPROPER SELECTION OR IMPROPER USE OF THE
PRODUCTS AND/OR SYSTEMS DESCRIBED HEREIN OR RELATED
ITEMS CAN CAUSE DEATH, PERSONAL INJURY AND PROPERTY
DAMAGE.
This document and other information from The Company, its subsidiaries
and authorized distributors provide product and/or system options for further
investigation by users having technical expertise. It is important that you
analyze all aspects of your application, including consequences of any failure
and review the information concerning the product or systems in the current
product catalog. Due to the variety of operating conditions and applications for
these products or systems, the user, through its own analysis and testing, is
solely responsible for making the final selection of the products and systems
and assuring that all performance, safety and warning requirements of the
application are met.
The products described herein, including without limitation, product features,
specifications, designs, availability and pricing, are subject to change by The
Company and its subsidiaries at any time without notice.
EXTRA COPIES OF THESE INSTRUCTIONS ARE AVAILABLE FOR
INCLUSION IN EQUIPMENT / MAINTENANCE MANUALS THAT UTILIZE
THESE PRODUCTS. CONTACT YOUR LOCAL REPRESENTATIVE.
!
!
! CAUTION
Polycarbonate bowls, being transparent and tough, are ideal for use with
Filters and Lubricators. They are suitable for use in normal industrial
environments, but should not be located in areas where they could be
subjected to direct sunlight, an impact blow, nor temperatures outside of
the rated range. As with most plastics, some chemicals can cause damage.
Polycarbonate bowls should not be exposed to chlorinated hydrocarbons,
ketones, esters and certain alcohols. They should not be used in air systems
where compressors are lubricated with fire-resistant fluids such as phosphate
ester and diester types.
Metal bowls are recommended where ambient and/or media conditions are
not compatible with polycarbonate bowls. Metal bowls resist the action of
most such solvents, but should not be used where strong acids or bases
are present or in salt laden atmospheres. Consult the factory for specific
recommendations where these conditions exist.
TO CLEAN POLYCARBONATE BOWLS USE MILD SOAP AND WATER
ONLY! DO NOT use cleansing agents such as acetone, benzene, carbon
tetrachloride, gasoline, toluene, etc., which are damaging to this plastic.
Safety Guide
For more complete information on recommended application guidelines, see
the Safety Guide section of Pneumatic Division catalogs or you can download
the
Pneumatic Division Safety Guide at: www.wilkersoncorp.com
