11 | PIR Ready VTR7300 Series-Installation Guide
Dual occupied setpoints adjustment
(Local occupied setpoint adjustment when “Stp Func” = Dual Stp)
 Heat/Cool setpoint toggle with MODE button to be active only in AUTO mode.
 If cooling, heating or off mode is active, function is disabled.
Single occupied setpoints adjustment
(Local occupied
setpoint adjustment when “Stp Func” = Attch Stp )
Unoccupied and stand-by setpoints adjustments
Setting of the stand-by and unoccupied setpoints is done through the network or through
configuration setup only.
Mode button menu sequence.
Modes presented to the user are dependent on the sequence of operation selected.
Default mode is shown in bold when sequence of operation parameter is changed.
AutoMode set to ON = Auto system mode ACTIVE
SEQUENCE SELECTED MODE MENU
0 = Cooling Only Off - Cool
1 = Heating Only Off - Heat
2 = Cooling / Heating
Cooling With Electric Reheat
Off
– Auto – Heat – Cool
3 = Heating With Electric Reheat Off - Heat
4 = Electric Reheat Only Off – Heat
COOLING
MODE
HEATING
MODE
OFF
MODE
AUTO MODE

Setpoint presented to user is the setpoint from the last
action taken by the Terminal Equipment Controller or
the one currently in use.

If the other setpoint is the one desired, then the
MODE button is used to toggle between the current
displayed one and the other
.
Cool XX.X
°F or °C
Heat XX.X
°F or °C
No access to
setpoint
Cool XX.X °F or °C or Heat XX.X °F or °C
Toggle to ( Heat or Cool )with MODE button
COOLING
MODE
HEATING
MODE
OFF
MODE
AUTO MODE

Setpoint presented to user is the setpoint from
the last action taken by the Terminal Equipment
Controller or the one currently in use.
 Both heating and cooling setpoints are changed
simultaneously while respecting the minimum
configured deadband

If the other setpoint is the one desired, then the
MODE button is used to toggle between the
current displayed one and the other.
Cool XX.X
°F or °C
Heat XX.X
°F or °C
No access
to setpoint
Cool XX.X °F or °C and Heat XX.X °F or °C
Both heating & cooling setpoints change simultaneously
Toggle from ( Heat or Cool ) using the system MODE button
