19 | PIR Ready VT7600 Series-Installation Guide
CONFIGURATION
PARAMETERS
DEFAULT VALUE
SIGNIFICANCE AND ADJUSTMENTS
PswrdSet
Configuration parameters
menu access password
Default value = 0
No password prompted This parameter sets a password access to prevent
unauthorized access to the configuration menu
parameters. A default value of “0” will not prompt a
password or lock the access to the configuration
menu.
Range is: 0 to 1000
Com addr Thermostat
networking address
Default value = 254
Range is: 0 to 254
Conditional parameter to BACnet MS-TP models
(VT76xxX5x00B)
Conditional parameter to Wireless models
(VT76xxX5x00W)
This parameter will only appear when a BACnet or
wireless network adapter is present. If the thermostat is
installed as a stand-alone unit or with an Echelon
adapter, this parameter will not be used or displayed
- For BACnet MS-TP models valid range to use is
from 1 to 127. Default value of 254 disables BACnet
communication for the thermostat.
- For wireless models valid range is 0 to 254 with a
maximum of 30 thermostat per VWG
PAN ID
Personal Area Network
Identification
Default value = 0
Range is: 0 to 1000
Conditional parameter to Wireless models
(VT76xxX5x00W)
This parameter will only appear when a wireless
network adapter is present. If the Terminal Equipment
Controller is installed as a stand-alone
(Network
Ready) unit or with a BACnet™ or Echelon™ adapter,
this parameter will not be used or displayed
This parameter (Personal Area Network Identification)
is used to link specific Terminal Equipment Controllers
to a single specific Viconics wireless gateway ( VWG )
For every Terminal Equipment Controller reporting to
a gateway ( maximum of 30 Terminal Equipment
Controllers per gateway ), be sure you set the SAME
PAN ID value both at the gateway and the Terminal
Equipment Controller(s).
The default value of 0 is NOT a valid PAN ID.
