Typical examples of a 2 event office schedule:
Ex. #1 Office building closed all weekend
Event Period #1 - Event #1 Period #1 - Event #2
Occupied Unoccupied
Setpoint
Cool Heat Cool Heat Daily
72 °F 70 °F 80 °F 62 °F Occupancy
Monday 7.00 AM 6.00 PM Day time only
Tuesday 7.00 AM 6.00 PM Day time only
Wednesday 7.00 AM 6.00 PM Day time only
Thursday 7.00 AM 6.00 PM Day time only
Friday 7.00 AM 6.00 PM Day time only
Saturday 12.00 PM * 12.00 PM * Unoccupied
Sunday 12.00 PM * 12.00 PM * Unoccupied
* Scheduling consecutive events to the same time will cause the Terminal Equipment
Controller to choose the last event as the time at which it will set its schedule. In the
above example, the Terminal Equipment Controller will control to the unoccupied set
point until 7:00 AM Monday.
Ex. #2 Commercial building which is occupied all weekend
Event
Period #1 - Event
#1
Period #1 - Event
#2
Occupied Unoccupied
Setpoint
Cool Heat Cool Heat Daily
72 °F 70 °F 80 °F 62 °F Occupancy
Monday 8.00 AM 5.00 PM Day time only
Tuesday 8.00 AM 5.00 PM Day time only
Wednesday 8.00 AM 5.00 PM Day time only
Thursday 8.00 AM 5.00 PM Day time only
Friday 8.00 AM 5.00 PM Day time only
Saturday 12.00 AM ** 11.59 PM ** Occupied
Sunday 12.00 AM ** 11.59 PM ** Occupied
** To schedule a day as occupied for 24 hours, set that day occupied time to 12:00 AM
and Unoccupied time to 11:59 PM There will be a 1 minute unoccupied period every
night at 11:59 PM with this schedule configuration.
Note: 12:00 PM = Noon
12:00 AM = Midnight
