QUICK START GUIDE
19
2
2
4,5
3
1920N 1920N 2560 2560
3
05/ 05/12 12/24 24
12 12:38 38
+ 0.0 0.0 + –
To record an image
See page 59 for details.
Snapshot mode icon
Focus frame
1. Remove the lens cap from the lens.
2. Open the monitor screen to turn on the camera.
• You can also turn on the camera by pressing the power
button.
3. Align the mode dial with “ ” (Snapshot mode).
• This causes “ ” (Snapshot mode) to appear on the
monitor screen.
4. Point the camera at the subject, use the monitor
screen to compose the image, and then press the
shutter button half way.
• When the camera finishes its Auto Focus operation, the
focus frame will turn green and the operation lamp will light
green.
5. Holding the camera still, gently press the shutter
button all the way down.
Operation lamp
Before using a commercially available memory card, be sure
to first format it using the camera’s formatting procedure. For
details about formatting a memory card, see page 169.
