3/32" x 4" x 30" BALSA SHEETS
F I G . 1 2
Join three 3/32 x 4 x 30 balsa sheets using masking tape as
shown.
Turn over and glue joints as shown.
Pin to a flat surface and allow to dry.
Remove tape.
Make 4 SETS of panels.
8
FIG. 13
Glue balsa half rib W-2A to RIB W-2.
Glue landing gear brace W -13 (PLY) to ribs W-3 and W-5
Make sets for RIGHT WING half and LEFT WING half.
S T E P
2
W-2
W-2A
W-5
W-3
PLY
W-13
W I N G
STEP
1
WING
