31
11.3. VX-2000PF Power Supply Frame
Panel: Surface treated steel plate, black (30% gloss), paint
483 (w) x 132.6 (h) x 324.8 (d) mm
5.5 kg
Side Panel ..... 2, Front panel .....1, Chassis ..... 1, Fixing bracket* ..... 1
VX-200PS (up to 3)
Finish
Dimensions
Weight
Product Composition
Usable Unit
• Accessories
Self-tapping screw (4 x 10) ...................... 16
Machine screw M3 x 6 ............................... 4
Rack mounting screw (5 x 12) .................... 4
Fiber washer .............................................. 4
11.2. VX-200PS Power Supply Unit
230 V AC (ER/UK), 220 – 230 V AC (SA), 50/60 Hz
580 W
Rated output: 210 W (29 V, 7.25 A) x 2
Peak output: 400 W x 2
M4 screw terminal, distance between barriers: 11 mm
Applicable cable diameter: AWG 14 – AWG 10 (line resistance within
10 mΩ/pair)
Cross sectional area: 2.0 – 5.5 mm 2
Max. 4 V
0 to +40°C
VX-2000PF
Surface-treated steel plate
135 (w) x 118.2 (h) x 333.8 (d) mm
13.2 kg
Power Source
Power Consumption
DC Power Output
Ripple Voltage at Imax B
(at VX-2000DS's DC Output)
Operating Temperature
Applicable Frame
Finish
Dimensions
Weight
• Accessories
Fuse (T3.15 A L) ........................................ 1
Power cable (2 m) ...................................... 1
Note: The design and specifications are subject to change without notice for improvement.
* The Fixing bracket is not supplied with the previous VX-2000PF. (Refer to p. 9, "Installation Precautions.")
