30
11. SPECIFICATIONS
11.1. VX-2000DS Emergency Power Supply
230 V AC (ER/UK), 220 – 230 V AC (SA), 50/60 Hz
240 W max.
Panasonic LC-X1265PG/APG (65 Ah)
Trickle charging
5 A max.
27.3 V ±0.3 V (at 25°C)
Temperature correction coefficient: –40 mV/°C
6, M4 screw terminal, distance between barriers: 11 mm
6 (25 A max. each), M4 screw terminal, distance between barriers: 11 mm
RJ45 female connector for connecting the VX-2000SF Surveillance Frame
Twisted-pair straight cable (TIA/EIA-568A standard)
Type of control signal: Battery check, AC power status, DC power status,
charging circuit failure, and battery failure
1 pair of positive and negative terminals
Applicable cable diameter: AWG 6 – AWG 0 (1/0) (Line resistance within
4 mΩ/total)
Cross sectional area: 16 – 50 mm 2
0 to +40°C
Panel: Surface-treated steel plate, black (30% gloss), paint
482 (w) x 88.4 (h) x 377.6 (d) mm
10.5 kg
Power Source
Power Consumption
Applicable Battery
Charging Method
Charging Current
Charging Output Voltage
Power Supply Input
DC Power Output
Control Connector
Battery Connection
Operating Temperature
Finish
Dimensions
Weight
• Accessories
Rack mounting screw (5 x 12) .................... 4
Fiber washer .............................................. 4
Blade fuse (40 A) ....................................... 3
Fuse (T3.15 A L) ........................................ 1
Insulating sheet .......................................... 1
Attention label (German) ............................ 1
Thermal insulating sheet ............................ 1
Power cable (2 m) ...................................... 1
(ER/UK version only)
Fastener hook ............................................ 4
Fastener loop ............................................. 4
Sticker (Declaration of compliance) ........... 1
Note: The design and specifications are subject to change without notice for improvement.
Blade fuse (40 A), Blade fuse (7.5 A), Fuse (7.5 A)
43.5 A
50 mΩ
43.5 A
43.5 A
0 A
Twisted-pair straight cable (TIA/EIA-568A standard)
Fuse ratings
Maximum output current draw from the battery
Maximum internal resistance of the battery and its
associated circuitry, Ri max
Rated maximum continuous output current, I max a
Rated maximum short duration output current, I
max b
Rated minimum output current, I min
Recommended cable parameter for DS-SF Link
