Tie Down Vector Dynamics Foundation System for Wind Zones IBC 2009 - Manual (Page 4)

Page 4 4/3/2013
Vector Dynamics
Foundation Systems
Component Parts List
Vector System 2000
Part # 59018
Single piece pads with straps
and slotted bolts
Concrete Vector System
Part # 59036
Single piece pads with
swivel straps and slotted bolts
Part # 59008
Single piece pads without
swivel straps and slotted bolts
Concrete Vector System
Part # 59049
Double block pads with
swivel straps and slotted bolts
Part # 59006
Double block pads without
swivel straps and slotted bolts
Longitudinal Stabilization
Hardware Kit for Concrete
Part # 59023
(for use with 59006 & 59008)
