FieldPilot
®
Kit CoNteNts
Unpack the installation kit and identify the required parts.
Item Part Number Description
Quantity
A
32-04040
Switch, Engage/Disengage, Momentary ..................................................................1
B
350-0024
Washer, Flat, 1/4” SST .............................................................................................4
C
350-0037
Washer, Narrow Flat - 3/8”, SST ..............................................................................2
D
350-0083
Nut, Whiz-Lock, 1/4”-20 SST ..................................................................................2
E
35-02181
Valve, FLDPLT PWM, CC, LS 1.1GPM ...................................................................1
F
35-03017
Manifold, 3 Port, PRRV ............................................................................................1
G
35-04085
Cartridge, PRRV 50-600psi .....................................................................................1
H
45-07703
Harness, SCM .........................................................................................................1
I
45-10103
Harness, Valve .........................................................................................................1
J
60-01016
Washer, Flat, 5/8” SST ............................................................................................1
K
60-04087
Bolt, Hex, 3/8-16 x 3-1/4” SST .................................................................................2
L
60-04090
Bolt, Hex, 1/4”-20 x 2” SST ......................................................................................2
M
60-04091
Bolt, Hex, 5/8”-11 x 1.5” SST ..................................................................................1
N
60-07027
Nut, NyLock 3/8-16, SST .........................................................................................2
O
60-07028
Nut, Whiz-Lock, 5/8”-11 SST ...................................................................................1
P
65-05134
Bracket, FieldPilot Valve Mount ...............................................................................1
Q
65-05194
Bracket, PRRV Mount ..............................................................................................1
R
68-01025
Hose, Hyd. - 3/8” x 54”, #6FJIC x #6FJIC90º ......................................................1
S
68-01095
Hose, Hyd. - 3/8” x 53”, #6FJIC x #6FJIC ................................................................3
T
68-01096
Hose, Hyd. - 3/8” x 60”, #6FJIC x #6FJIC ................................................................1
U
68-01097
Hose, Hyd. - 3/8” x 25”, #6FJIC x #6FJIC ................................................................1
V
68-01158
Hose, Hyd. - 3/8” x 13”, #6FJIC x #6F JIC 90º ........................................................1
W
68-01203
Hose, Hyd. - 1/4” x 19”, #6FJIC x #6FJIC 90º .........................................................1
X
68-02019
Adapter, Hyd. - #6MJIC x #6MORB .........................................................................2
Z
68-02022
Adapter, Hyd. -Run Tee #6 JIC ................................................................................5
AA
68-02070
Adapter, Hyd. Plug - #6MORB .................................................................................1
