FieldPilot ®
Item Part # Description Illustration
A 32-04040 Switch, Engage/Disengage
B 350-0024 Washer, Flat, 1/4” SST
C 350-0083 Nut, Whiz-Lock, 1/4”-20
SST
D 350-0136 Bolt Hex, 1/4”-20 X 2-1/2”
SST
E 35-02182 Valve, FLDPLT, PWM OC,
4.0GPM
F 35-02155 Valve Counter Balance
G 45-07703 Harness, SCM
H 45-10103 Harness, Valve
A
B
45-10103
DC: xx/xx
