LH 1200S O PERATORS MANUAL
6 LH A GRO
SEED DRILL
A: B:
Work time
Work time
Forward speed Forward speed
Area trip counter Area trip counter
Area total counter Area total counter
Shaft speed (RPM) Seed application rate
Seed consumption
The above examples show that three basic functions, TIME, FORWARD SPEED,
and AREA are always available. The secondary functions can be selected as
required.
The monitor can measure distance in metres as an extra function. This function
requires a special encodement (code) and can, therefore, only be used by itself.
All other information displayed is incorrect when this function is selected.
When the boom section function is activated, the display will change between the
selected function and the boom section status. The display changes every other
second.
When forward speed is selected and the area override sensor is activated an “r”
is displayed on the left-hand side of the display.
The LH 1200S is equipped with a system test program, which enables the user to
test all connected sensors. For more information, see the ”SYSTEM TEST”
chapter on page 25.
