background image

LH 1200S O

PERATORS MANUAL

26

LH

A

GRO

TRAILER PLUG CONNECTIONS

SPRAYER

Sensor

Wire colour

Trailer plug pin no.

Blue (0V)

5

Brown (signal)

2

Flowmeter

Black (+12V)

6

Blue (signal)

4

Wheel sensor

Brown (0V)

5

Blue (signal)

7

Implement sensor

Brown (0V)

5

FERTILISER DISTRIBUTOR/SEED DRILL

Sensor

Wire colour

Trailer plug pin no.

Blue (+12V)

6

Brown (0V)

5

Volume sensor

Black (signal)

2

Blue (signal)

4

Wheel sensor

Brown (0V)

5

Blue (signal)

7

Implement sensor

Brown (0V)

5
