814-AB Sprayer Monitor

Programming and Operating Manual US 9/98

Page 5 of 15

System Setup Mode

The System Setup Mode contains the programming steps that customize the monitor to the
sprayer or sprayer components. These include calibration steps and parameters that, once
programmed, will likely never change. An overview of all programming steps is shown in
“Appendix B: Overview of Programming Steps”.
To enter the System Setup Mode:

First be sure that the console is ON (if not turn it on by pressing the Pro key and wait until
the normal display is visible).

Check if the Master switch is OFF

Then press and hold the Pro key for 3 seconds to enter the System Setup Mode.

S

ELECTING

U

NITS

Default = US

>US units

Select the units that the monitor will be operating in using the Up or Down keys. Select US
units for English measurement units or SI units for metric measurement units.
Depress the

P

RO

key to accept the value and advance to the next program step.

S

PEED

S

ENSOR

C

ALIBRATION

Default = 250 pulses/300 feet (100 meters)

>250 puls/300ft

The speed sensor needs to be calibrated in order to provide the proper speed and area
readings. The value for this step is the number of pulses generated by the speed sensor in
300 ft (100 meters).
