Name Values
Description
OF CMP Computer output format
(Output Format) SCB Scoreboard output format
1* 290 Output format for 290 and 695 printers * (See Printer Section)
1* 695 Output format for 795 printers* (See Printer Section)
1*LD2 Output format for LD2 printers * (See Printer Section)
CO F On demand output with PRINT key
(Continuous Output) T Continuous output of data (Typically used with computer and scoreboards)
RS 232 Serial interface is RS-232 (Standard)
(Interface) or 20 mA current loop (Optional)
422 Serial interface is RS-422 (Optional)
485 Serial interface is RS-485 (Optional)
B 150 Baud rate at 150 bits per second
(Baud Rate) 300 Baud rate at 300 bits per second
600 Baud rate at 600 bits per second
1200 Baud rate at 1,200 bits per second
2400 Baud rate at 2,400 bits per second
4800 Baud rate at 4,800 bits per second
9600 Baud rate at 9,600 bits per second
19200 Baud rate at 19,200 bits per second
P NONE Parity disabled
(Parity) ODD Parity set for odd
EVEN Parity set for even
DBIT 7 Data bits at 7 bits
(Data Bits) 8 Data bits at 8 bits
FC F If not using flow control
(Flow Control) T If using flow control
STTN F If a station number is not required
(Station) T If a station number is required (Choose station 1 – 99)
SN F If the serial number does not need to be changed
(Serial Number) T If the serial number must be changed (Incremented number for the output)
SMP F If not changing the sample scale
(Sample Scale) T If changing the sample scale
(Counting operation only)
CNT F If not changing the count scale
(Count Scale) T If changing the count scale
(Counting operation only)
TIME F If not setting the time and date
(Option) T If setting the time and date
LOCK F If not locking keyboard access to parameters
(Parameter Lockout) T If locking keyboard access to parameters
Used in conjunction with Jumper J8 on the 810- 825 boards
DR F Dual Range Disabled
(Dual Range) T Dual Range Enabled
1* Available only with Print Drivers (See Printer Section)
