Jumper Settings
In order for the 810/825 to operate as desired hardware, Jumpers must be set properly.
Most of the jumper setting’s are set correctly at the factory and never need to be altered, but
occasionally there is a need to alter a jumper setting, therefore they are shown below
Jumper List
Number Name
Setting Description
J8
NTEP/CTS NTEP Enable NTEP operation
CTS Enable CTS flow control
J9 RAM 8K Use 8K RAM
32K Use 32K RAM
J10 EPROM 256 Use 27C256 EPROM
512 Use 27C512 EPROM
J12 Back light On Back light on
Off Back light off
J13* Load Cell Sense (+) On Not using load cell sense wires (+)
Off Using load cell sense wires (+)
J14* Load Cell Sense (-) On Not using load cell sense wires (-)
Off Using load cell sense wires (-)
*NOTE: Jumpers “J13” and “J14” must both be either connected or disconnected to avoid
improper weighing and/or possible damage to the indicator.
