Specifications
DW810 Physical Specifications
Material:
NEMA 1 Enclosure – ABS DFA/R with EMI/RFI shielding
NEMA 4 Enclosure – Stainless steel
NEMA 12 Enclosure – Mild steel
NEMA 7 Enclosure – Cast aluminum
Dimensions:
NEMA 1 Enclosure – 6.25” H x 9.5” W x 1.25” D
NEMA 4 Enclosure – 6.25”H x 9.5”W x 2.50”D
NEMA 12 Enclosure – 8.0”H x 10.0”W x 4.0”D
NEMA 7 Enclosure – 14”W x 14”W x 6.00”D
Weight:
NEMA 1 Enclosure – 3 lbs.
NEMA 4 Enclosure – 7 lbs
NEMA 12 Enclosure –10 lbs.
NEMA 7 Enclosure – 50 lbs
Power Requirement:
NEMA 1 Enclosure – 12VDC, 500 mA
NEMA 4 Enclosure – 117 VAC ± 10VAC, 60 Hz
NEMA 12 Enclosure – 117 VAC ± 10VAC, 60Hz
NEMA 7 Enclosure – 117 VAC ± 10VAC, 60 Hz
825 Physical Specifications
Dimensions:
12.375” W x 16.55” D x 3.5” H
Power Requirements:
117 VAC ± 10 VAC, 60 Hz
Operating Temperature: -19°C (14 F) to 40° C (104 F)
SPECIFICATIONS
