Scoreboard Output Format
If the Scoreboard Output Format is to be used, then the Output Format Parameter must be set
to SCB (See Configuration).
The Scoreboard Output Format is as follows: Value CR LF
Name Characters
Description
Value
7 Displayed
weight
or
quantity
CR
1
ASCII Carriage Return (0D Hex)
LF
1
ASCII Line Feed (0A Hex)
External Control
External Keys
The serial interface allows an external device to transmit data (external keys) to the
DW810/825, which mimic the keypad operation completely.
External Key ASCII
Value
Hex Value
Decimal
Value
ZERO
a 81
097
PRINT b 62
098
UNITS c 63
099
TARE
d 64
100
GROSS/NET
9 67
103
PARAMETERS
z 7A
122
External Switch
An external switch is a hardware switch used to mimic a keypad operation completely.
The DW810/825 allows for only the ZERO external switch.
A momentary, normally open, switch must be connected between “Pin 01” and “Pin 09”.
External ZERO is activated when the switch is closed.
To avoid erratic operation the switch cable must be less than 10 feet.
