Output Formats
The DW810/825 is capable of transmitting one of the following formats: Optional Printer Output
Format (See Printer Section), Computer Output Format, and Scoreboard Output Format. A
format may be transmitted either on demand or continuously (See Parameter Setup). Motion
is tested only when transmitting the Printer Output Format on demand.
Computer Output Format
If the Computer Output Format is to be used then the output format parameter
must be set to CMP (See Configuration).
The Computer Output Format is as follows:
STX Mode
Value
Pad Status
Units CR LF
Name
Characters Description
STX
1
ASCII Start of Text (02 Hex)
Mode
1
“G” if gross weight mode
1
“N” if net weight mode
1 “Q”
if
quantity
(count)
mode
Value
7
Displayed weight or quantity
Pad
1
ASCII Space (20 Hex)
Status
1
“M” if scale is in motion
1
“0” if scale is in overload
1
ASCII space (20 Hex) if scale is stable
Units
3
“lb.” if in weight mode and unit is pounds
3
“kg” if in weight mode and unit is kilograms
3
“g” if in weight mode and unit is grams
4
“pcs” if in count mode
CR
1
ASCII Carriage Return (OD Hex)
LF
1
ASCII Line Feed (OA Hex)
