Operational
Internal Counts:
18,777,215
Display Counts:
10,000 recommended (50,000 maximum)
Display Update Rate:
10 times per second
Input Sensitivity:
0.5uV per graduation
Linearity:
0.01%
of
full
scale
Overload Capacity:
105% of full scale
Load Cell Excitation:
10VDC (9,350 ohm load cells or 16,750 ohm load cells)
Calibration
Method:
Full keyboard digital calibration
Range: 0.5
mV/V
to
3.0
mV/V
Capacity:
2 to 500,000 lb., kg., or g
Display
Type:
6 characters, 14 segment LCD with 20 annuniciators
Enunciators:
SCALE 1, 2, 3, 4 GROSS, NET, TARE k, g, lb., pcs,
SP3, SP2, SP1, ID, LO BAT, M, -, and ->0<-
Backlight:
Yellow/Green
LED
Serial Interface
Type:
RS-232
(bi-directional,
full-duplex)
*RS-422
(bi-directional,
half-duplex)
*RS-485
(bi-directional,
half-duplex)
*20mA
Current
Loop
(transmit
only)
Baud Rate:
Selectable from 150 to 19,200 bits per second
Parity:
Selectable
from
none,
odd,
or
even
Data Bits:
Selectable from 7 or 8 bits
Start
Bits
1
Stop
Bits
1
Flow Control
Hardware flow control available for RS-232 only
Options
* Battery Operation
* Time and Date
* RS-422, RS-485, or 20mA Current Loop
* 4-20 mA or 0 – 10 VDC Analog Output
* 220 VAC, 50 Hz Operation
SPECIFICATIONS
