18 | P a g e
OPERATION (CONTINUED)
S ETTING U P THE I NCUBATOR
Perform the following steps and procedures to prepare the incubator for use each time it is installed in a
new location:
1. Verify the workspace’s power supply and incubator’s data plate requirements match.
2. Check that the fuse is installed in the power inlet.
3. Plug the power cord into an earth grounded electrical outlet.
4. Place the Power switch in the ON position.
5. Complete the following procedures in order:
a. Set the Temperature Set Point
b. Calibrate the Temperature Display
c. Set the Over Temperature Limit Control
S
ET THE
T
EMPERATURE
S
ET
P
OINT
Perform these steps to prepare the unit for calibration.
1. Turn the Over Temperature Limit control dial clockwise to the maximum position indicated by
the largest dot. This prevents the Over Temperature Limit system from interfering with the set
point and calibration procedures.
2. Press either the Up or Down key one time on the Temperature Control panel to activate the
temperature set point mode. The Set Temperature digital display will start to blink, going from
bright to dim. Some models may briefly display
the letters “SP” to indicate a Set Point is being
displayed. While blinking, the Set Temperature display shows an adjustable temperature set
point.
3. To change the set point, press either the Up or the Down key to adjust the set point up or down.
If neither key is pressed within 5 seconds, the Set Temperature display stops blinking and returns
to displaying the current temperature of the incubator.
4. Adjust the set point to the temperature you will use during normal operations.
5. Wait 5 seconds after entering your set point. The display will stop flashing, and the set point is
now saved in the controller. The incubator will now automatically adjust to match your set point.
Figure 11: SRI3P Control Details
