Page 11
.
11 |
P a g e
INSTALLATION (CONTINUED)
I
NSTALL
S
IDE
A
IR
D
UCTS
,
SRI20P
Two (2) side air ducts are packed with the accessories of the SRI20P. Install the air ducts from the corner
top and bottom hooks into the provided slots on the sides of the chamber. The SRI3P and SRI6P
incubators do not use Side Air Ducts.
Figure 1: SRI20P Air Duct Panel
Note: The air duct panels play an important role maintaining even heat distribution inside the SRI
20P’s
incubation chamber. Failure to install both air duct panels
may adversely impact the incubator’s
temperature uniformity.
