14 | P a g e
INSTALLATION (CONTINUED)
SRI6P and SRI20P Sliding Shelf Installation
Note: The SRI6P does not come with a sliding shelf. Sliding shelves for the SRI6P must be purchased
separately.
1. Laterally insert the sliding mounting bracket’s 2 pairs of twin tabs (front and back) into the slots on
the sides of the incubator chamber. See Figure 6.
2. Slide the bracket down so that the tabs are securely seated in the mounting slots. See Figure 7.
Secure the bottom flange of the sliding mounting bracket to the side of the chamber interior by
threading and screwing in 2 screws, at the front and back of the flange. See Figures 8 and 9.
Figure 6: Sliding Shelf Mounting
Bracket Installation Figure 7: Sliding Shelf Mounting
Bracket Installation
Figure 8: Sliding Mounting Bracket
Screws Figure 9: Sliding Mounting Bracket
Front Screw Installed
