CONTROL PANEL OVERVIEW
Control Panels: SCO58 Top, SCO40 SCO31 Bottom
Power Switch
The main power switch on the control panel controls all power to the unit and its systems. The
switch illuminates when in the I on position on the SCO58. A green pilot light labeled Power On
illuminates on the SCO40 and SCO31
Temperature Display and Controls
Marked SET TEMPTERATURE, the incubation chamber temperature control panel comes with a
green digital display that shows the air temperature within the chamber, accurate to 0.1°C. The
display also shows the user-selected temperature set point, and can be used to enter offsets during
temperature calibrations. The controls consists of an UP / DOWN arrow pad for inputting set point
temperatures and performing calibrations. Red LED indicator lights marked HIGH and LOW
illuminate whenever an alarm condition associated with the chamber’s temperature is reached. The
yellow LED marked MUTE illuminates whenever an audible alarm is being muted.
Heating Activated Light
The green pilot light labeled HEATING ACTIVATED illuminates whenever the incubator heating
element is energized.
