6

SeaLand 4700 Series VacuFlush Toilet

Components

5 Specifications

5.1 Materials

Toilet body: vitreous ceramic
Toilet seat: thermoset plastic resin or wood (seats vary according to toilet model)
Discharge fitting: PVC

5.2 Approvals

CE, REACH and ROHS compliant components

5.3

Toilet installation specifications

Electrical

Amp draw (average)

2 amps at 12 V DC; 1 amp at 24 V DC

Fuse

2-amp internal fuse (resettable) *

Water

Supply

Fitting

0 .5 in . NPT

Flow rate

4 .0 gpm/15 lpm minimum required at toilet

Discharge

Size

1 .5 in ./38 mm ID PVC pipe or sanitation hose

Horizontal run

50 ft ./15 m maximum to vacuum source

Vertical run

6 ft ./1 .8 m maximum to vacuum source

Required

components

Electric flush switch

Dometic VFS or VFP switch (purchased separately)

Status panel

VacuFlush status panel (for flush handle toilets only)

Vacuum source

VacuFlush vacuum generator or

VacuFlush holding tank system (purchased separately)

* Circuit board fuse resets by turning toilet’s electrical power off, then back on .
Specifications subject to change without notice .

5.4

Dimensions

(fig .

3

, p . 2) All dimensions may vary ±3/8 inch (10 mm)

Ref.

Dimension

A

19 in . / 483 mm

B

14 .75 in . / 375 mm

C

21 .5 in . / 546 mm

D

17 .75 in . / 451 mm - seat height

E

17 .125 in . / 435 mm

F

10 in . / 254 mm - centerline

rough-in

G

33 .75 in . / 857 mm - seat lid up

Ref.

Dimension

A

19 in . / 483 mm

B

15 .875 in . / 403 mm

C

21 .5 in . / 546 mm

D

17 .75 in . / 451 mm - seat height

E

17 .125 in . / 435 mm

F

10 in . / 254 mm - centerline

rough-in

G

33 .75 in . / 857 mm - seat lid up

Models with wall-mounted flush
switch

Models with flush handle
