5

SeaLand 4700 Series VacuFlush Toilet

Intended use

4 Components

4.1

4700 series VacuFlush toilet

(fig .

1

, page 2)

(fig .

2

, page 2)

Ref.

Description

1

Anti-siphon vacuum breaker

2

Electric water valve

3

Water supply line

4

Status panel cable connector

*

5

Vacuum generator cable connector

6

Flush switch cable connector

7

Circuit board

8

Flush ball motor/drive linkage

9

Flush handle (alternate model)

*

10

Flush handle switch

*

11

Service mode switch

*

Component of flush handle toilet model only .

Refer to complete parts list (packed separately) for
additional information .

Ref.

Description

A

VacuFlush switch/status panel

B

VacuFlush status panel

(for toilet with flush handle only)

VacuFlush switch panel can be fitted with generic
frame or one of several popular Vimar and Gewiss
frames .

4.2

Typical VacuFlush toilet system (marine)

(fig .

4

, page 2)

Ref.

Description

1

4700 series VacuFlush toilet

2

VacuFlush switch/status panel

3

Vacuum generator

4

Holding tank status panel

5

Holding tank (waste)

Ref.

Description

6

Vent filter

7

Discharge pump

8

Overboard discharge fitting

9

Air vent fitting

10

Dockside discharge fitting

Some VacuFlush toilet systems combine the vacuum generator (3) and holding tank (5) into one unit (VacuFlush holding tank system) .
Contact boat or vehicle manufacturer for complete information on your toilet system .
