12

SeaLand 4700 Series VacuFlush Toilet

Maintenance/winterizing/service

Problem

Possible Cause

Service Instruction

2 . Water enters toilet bowl, but

toilet does not flush .

a . Green “OK to Flush” light is not

lit on status panel .

b . Electrical failure from flush

switch or flush handle to toilet .

c . Flush switch or handle may be

defective .

d . Loose flush ball motor wires .

e . Defective flush ball motor .

f . Flush ball motor drive arm

failure .

g . Drive linkage failure .

a . Check for loose/defective wires

between vacuum switch (on

vacuum generator) and wire 6 of

toilet circuit board .

b . Check for loose/defective wires

between flush switch or handle

and pins 2 and 4 of toilet circuit

board .

c . Replace if necessary .

d . Check for loose wires between

motor and toilet circuit board

pins 17 and 18 .

e . Replace if necessary .

f . See page 15 for replacement

instructions .

g . See page 15 for replacement

instructions .

3 . Water does not enter toilet bowl,

but toilet flushes .

a . Blocked water supply .

b . Loose/defective wires .

c . Defective water valve .

d . Defective circuit board on toilet .

a . Clear blockage in water line or

filter screen at water valve inlet .

b . Check wires between water

valve and toilet circuit board pins

15 and 16 .

c . Replace water valve .

d . Replace toilet circuit board .

4 . Water does not enter toilet when

pressing “Add Water” switch or

raising flush handle .

a . Electrical failure .

b . Defective flush switch or handle .

c . Defective circuit board on toilet .

a . Check wires between “Add

Water” switch or flush handle and

toilet circuit board pins 1 and 4 .

b . Replace flush switch or handle .

c . Replace toilet circuit board .

5 . Water does not shut off and

toilet bowl overflows .

a . Debris inside water valve or

defective water valve .

b . Defective circuit board on toilet .

a . Replace water valve .

b . Replace toilet circuit board .

6 . Flush ball cycles constantly

between open and closed

position .

a . Cam switch needs adjusted to

align flush ball .

b . Defective cam switch .

c . Defective drive linkage .

d . Defective rotor shaft cam .

a . See page 14 for cam switch

adjustment instructions .

b . Replace cam switch .

c . Replace drive linkage . See page

15 for instructions .

d . Replace rotor shaft cam . See

page 15 for instructions .

7 . Flush ball opens slowly .

a . Excessive drag between flush

ball and seal .

b . Defective spring assembly .

a . Clean surface of flush ball and

under edge of seal . Lubricate

with silicone grease or alcohol-

free cooking spray .

b . Replace spring .

8 . Flush ball does not close

completely .

a . Cam switch needs adjustment/

flush ball alignment or

replacement .

b . Rotor shaft cam is loose or

defective .

a . See adjustment/alignment or re-

placement instructions on pages

14-15 .

b . See replacement instructions on

page 15 .
