13

SeaLand 4700 Series VacuFlush Toilet

Maintenance/winterizing/service

Problem

Possible Cause

Service Instruction

9 . Flush ball does not open

completely .

a . Rotor shaft cam is loose or

defective .

b . Weak or defective spring

assembly .

c . Excessive drag between flush

ball and seal .

a . See instructions for repair or

replacement on pages 14-15 .

b . Replace spring .

c . Clean surface of flush ball and

under edge of seal . Lubricate

with silicone grease or alcohol-

free cooking spray .

10 . Squeaky noise occurs during

flush cycle .

a . Lubrication needed between

flush ball and seal .

b . Lubrication needed between

drive arm/linkage joint .

a . Lubricate with silicone grease or

alcohol-free cooking spray .

b . Lubricate joint with silicone

grease .

11 . Water does not stay in toilet

bowl (leaks between flush ball

and seal) .

a . Flush ball seal is worn and

needs replaced .

b . Flush ball is scratched or worn

and needs replaced .

c . Cam switch/flush ball alignment

needs adjustment .

d . Bolts that hold base to toilet

need tightened to 20-25 in .-lbs .

a . See instructions on page 14 for

replacement .

b . See instructions on page 15 for

replacement .

c . See instructions on page 14 for

adjustment .

d . DO NOT OVERTIGHTEN or

damage to toilet may occur .

12 . Toilet flushes in both “Add

Water” and “Flush” positions .

a . Defective circuit board on toilet .

a . Replace toilet circuit board .

13 . Water leaks from toilet onto

floor .

a . Loose water line connection .

b . Defective water valve .

c . Toilet bowl seal is defective .

d . Mounting bolts holding base to

toilet need tightened to 20-25

in .-lbs .

a . Tighten water line connections .

b . Replace water valve .

c . Replace bowl seal . See

instructions on page 14 .

d . DO NOT OVERTIGHTEN or

damage to toilet may occur .

14 . Green “OK to Flush” light does

not illuminate, but toilet flushes .

a . Loose wire at circuit board on

toilet .

b . Loose wire at status panel .

c . Defective green light .

d . Defective circuit board on toilet .

a . Check wire connected to pin 3

of toilet circuit board .

b . Check green wire at status

panel .

c . Replace status panel .

d . Replace toilet circuit board .

15 . Red “Do Not Flush” light does

not illuminate .

a . Loose wire at circuit board on

toilet .

b . Loose wire at status panel .

c . Loose or defective wire from

“full tank” shut-down relay .

d . Defective circuit board on toilet .

a . Check wires connected to pins 5

and 7 of toilet circuit board .

b . Check red wire at status panel .

c . Repair or replace wire .

d . Replace toilet circuit board .

16 . Flush ball opens and closes,

but waste does not leave

bowl (no vacuum) .

a . No electrical power to vacuum

pump .

b . “Full Tank” shut-down relay

prevents vacuum pump from

operating .

c . Blockage inside bottom of toilet

base .

a . Check power wires, fuse or

circuit breaker to vacuum pump .

b . Pump out holding tank .

c . See instructions to clear

blockage (section 7 .5, p .10) .
