Form P-RIH/VR, PN 272513, Page 4
CODE 17 -
Venter
Motor
Capacitor
CODE 21 -
Pressure
Switch
CODE 25 -
Transformer
CODE 26 -
Relay
8-
Gas
Valve
Bottom View
with Access
Panels
Removed
26-Relay
(optional)
23-
Ignition
Controller
21-Pressure
Switch
24-S
park
Electrode
25-Transformer
Burner Section
(Access Panel Removed)
Control Section
(Hinged Access Panel not illustrated)
27-Terminal
Board, 24V
Ground
Screw
9-Orifice
7-
Burner
8-Gas
Valve
21-Pressure Switch
View “through”
Side of Control
Box
13-
Venter
Housing
Burner Section Control Compartment
14
1
Combustion
Chamber
Tube
CODE 27 - 24V
Terminal Strip
CODE 24 - DSI
Ignition Electrode
Model VR Burner/
Control Box (cont’d) -
See P/NS’s on page 3.
Model VR Tubes, Reflectors, and Options
38
39 - Reflector clips and screws are
shipped in the hardware bag.
CODE 40 - Reflector
End Cover
35A
36
37
35B
32
34
30
31
33
CODE Description All Sizes
30 Combustion Chamber Tube 205545
31 Combustion Chamber Tube Gasket 116029
32 10-ft Heat Exchanger Tube 205541
33
Compression Coupling w/all Hardware (Coupling is used
for all tube to tube connections & tube to vent pipe.)
205546
34 Turbulator Section 116019
35A Wire Reflector Retainer Replaces P/N 205543 209321
35B Tube and Reflector Hanger Bar 209322
36 Reflector Bracket 205586
37 "U" Bolt with brass nuts 131785
38
10-ft Reflector (NOTE: As of 6/12, Model VR reflectors
are made of aluminized steel and may be used to
replace aluminum reflectors.)
268220
39 Clip-on, spring steel receptacle nut 196336
Tube Packages include tubes, reflectors, and hardware.
Package ID VRE VRF VRG VRH
Package P/N 205204 205205 205206 205151
Required for 20 ft length 1 - - -
Required for 30 ft length - 1 - -
Required for 40 ft length 1 - 1
Required for 50 ft length 1 - - 1
Required for 60 ft length - 1 - 1
Required for 70 ft length - 1 2 -
Option Designation CD27
Option Package P/N 205762
Description Qty P/N
Reflector End Cover 2 268218
Screw #10-32x1/2" lg 8 113275
Nut #10-32 Keps 8 26490
Replacement Parts -
Model VR (cont’d)
P/N’s and Components of the Hardware Packages included in Tube
Pkgs VRE, VRF, VRG, & VRH listed above
Tube
Pkg
Replacement
Hardware Pkg
Qty of Components by CODE Plus each hardware
package includes (6)
#10 x 1/2” sheetmetal
screws, P/N 11813,
and (4) #10x1/2” long
Teks, P/N 37661
33 34 35A&B 36 37 39
VRE P/N 209401 2 4 3 3 3 2
VRF P/N 209402 3 3 4 4 4 2
VRG P/N 209403 2 1 2 2 2 2
VRH P/N 209404 3 2 3 3 3 2
Venter Motor and
Wheel Components
