Form P-RIH/VR, PN 272513, Page 1
Applies to: Infrared Heater
Model VR and Models RIH/RIHV
Form P-RIH/VR (Version C)
Obsoletes Form P-VR/TRP/RIH (Version B)
Model VR
(field assembled)
A
Air Flow Switch 7
High Altitude Kit 3
B
Burner/Control Box 3
Vent Adapter Box 6
Reflector Bracket 4, 5
Burner Assy 8
C
Capacitor 4
Venter Motor Capacitor 3
Chain 7
Chain Hanging Kit 7
Hanging Chain Kit 6
Outside Combustion Air Inlet 6
Combustion Chamber Tube 4
Conduit 7
Angle Connector 7
Stainless Flex Connector 7
Controls 7
Gas Conversion Kits 3
Input Conversion Bag 3
Coupling 4, 5
D
Date of Manufacture 2
Door 3
E
Electrode Assembly 3
G
Tube Gasket 4
Gas Valve 3, 7
Grommet 3
H
Burner/Control Box Hanger 3
Hanger Bar 4, 5
Hardware Bag 5
I
Ignition Control 3
Ignition Detection Control 7
Ignition Electrode 4
Ignitor 7
M
Main Burner Assembly 3
Manifold 8
Venter Motor 3
Multiple Heater Control Pkgs 6
N
Spring steel receptacle nut 4
O
Orifice 8
Orifice Adapter 3
P
Burner Box Access Panel 3
Pressure Switch 3, 4
R
Rating Plate 2
5-ft Reflector 5
10-ft Reflector 4
Parabolic Reflector 8
Reflector Assembly 8
Reflector clips 4
Reflector End Cover 4
Reflectors 4
Relay 3, 4, 6
Restrictor Plate 3
S
Combustion Air Inlet Screen 3
Screen 8
Sensing Tube 3
Serial No 2
Heat Shield 8
Side Shield 5
Size Conversion 2
T
Terminal Strip 3, 4
Thermostat 7
Thermostat Bracket 6
Thermostat Cover 7
Transformer 3, 4, 6
5-ft Tube 5
10-ft Heat Exchanger Tube 4
“L” Tube 5
“U” Tube 5
Tube Packages 4
Tubes 4
Turbulator Section 4
Turnbuckle 7
U
“U” Bolt 4
V
Dual Vent Kit 6
Vent Cap 6
Venter Housing 3
Venter Wheel 3
W
Wire Grid 8
Wire Harness 7
Wire Reflector Retainer 4
Models RIH/
RIHV
High-
Intensity,
Infrared
Heater
Rating Plate and Serial No. (Model VR) ...................................................2
Replacement Parts - Tubular, Low-Intensity Model VR .......................3-7
Replacement Parts - High-Intensity Infrared Models RIH/RIHV .........7-8
Table of Contents
INDEX
Website with downloadable files - www.RezSpec.com
Form I-VR, Model VR Installation, Operation, Maintenance, and Service
Form T-VR-CNFG, Model VR Configuration Manual
Form CP-VR-GC, Model VR Gas Conversion
Form I-RIH, Model RIH/RIHV Installation, Operation, Maintenance, and Service
References
Replacement Parts
Low-Intensity, Tubular, Infrared Heater
