Form P-EEDU, P/N 263547R1, Page 4
(replaces
P/N 14747)
28
19
22
21
20
17
16
23
24
11
14
13
12
10
15A
15B
EEDU
Unit
1
EEDU
Unit
2
4 (102mm)
C
B
D
E
Item B - Tie Plate
Item A - Filler
Plates (2)
Coupling Kits for 2, 3, 4, or 5 Furnaces
Flue Collection and
Venter Assembly
Code 18A,
Capacitor,
P/N 163894
Code 21, Venter Relays
Coupling Kit, P/N 57963 (Same as
Option CR1), for Two Furnaces
Item Qty
P/N
Description
A
2
57964 Filler Plate
B
1
57965 Tie Plate
C
2
9557 Threaded Socket As-
sembly
D
2
5095 3/8-16 x 1-1/4" lg Hex
Head Bolts
E
2
5197 Split Ring Lock Washer
F
20
11813 #10 x 1/2" lg Sheetmetal
Screws
Additional
Kits:
3 Furnaces -
P/N 82854 (Opt CR2)
4 Furnaces -
P/N 82855 (Opt CR3)
5 Furnaces -
P/N 82856 (Opt CR4)
Venter Relay
Replacement
Kit,
P/N 263527
Venter Relay used after
8/2011, P/N 211411,
24VAC, DPDT, and
Socket, P/N 211415
Code Description
75
100
125
140
170
200
225
250
300
350
400
10 Flue Collection Box
Assembly
Beginning with
Series 6
140907
140898 140899 140900 140901 140902 140903 140904 140905 140906
11
Venter Support Angle/Duct Support
63178
63179
12 Orifice Plate
63167
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
13 Exhaust Collar and
Pipe Assembly
Prior to Series 6
61051
61054
67880
Beginning Series 6
61051
61054
61051
67880
143184
14 Venter Support Plate
63110
62545
N/A
N/A
N/A
15A Blower Housing (includes housing & collars)
61064
61072
61075
15B Cover Plate
29594
29597
16 Venter Wheel, 5/16" bore, Torrington
29791, Torrington AA326-215-1
29792, AA408-228-1
17 Venter Fan Blade RHF
29793
18A Capacitor
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
163894 (replaces 103181)
18B Capacitor Boot, Syntex #M-78
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
103182
19 Venter Junction Box Mounting Bracket
31393
20 Venter Junction Box
29595
21 Relay
211411 (To replace Relay P/N 14747 used prior to 8/2011, order Replacement Kit P/N 263527.)
22 Venter Junction Box Cover
29596
23 Switch Bracket
61070
24 Pressure Switch IS20232-5272 (black
plastic)
205821 (To replace metal pressure switch used prior to 9/2003, order kit P/N 177633.)
25 Pressure Switch Tubing, Silicone
147904, 7"
177293, 8-1/4"
26 Fuse 1.6 Amps (C.G.A. prior to 10/89 only)
61541
27 Vent Terminal Cap
110051, 4"
110052, 5"
110053, 6"
28 Venter Motor
115 volt
61069, Fasco 7121-4861
87434, Fasco 7162-1775
208 volt
30249, Fasco 7162-0186 (replaces 62814, 208/230V motor)
30249, Fasco 7162-0186
230 volt
29571, Fasco 7162-0158 (replaces 62814, 208/230V motor)
29571, Fasco 7162-0158
Venter Motor and Wheel
115 volt
63169
63174
Assembly (including
Codes 16, 17, 19, 20, 22,
23, & 28)
208 volt
64858
64859
230 volt
64858
64863
Venter Sub-Assembly
(complete including
Codes above plus 15A&B)
115 volt
65146
65149
65152
208 volt
65396
65397
65398
230 volt
65396
65397
65401
