28
Table 10. B6BM MCA & MOP Data
B6BM MINIMUM CIRCUIT AMPACITY & MAXIMUM OVERCURRENT PROTECTION
CABINET CAPACITY
HEAT KIT
MODEL
NUMBER
H6HK-
240 VAC, 50 & 60 HZ, SINGLE PHASE 208 VAC, 50 & 60 HZ, SINGLE PHASE
MCA MOP MCA MOP
CIRCUIT A CIRCUIT B CIRCUIT C
SINGLE CIRCUIT
CIRCUIT A CIRCUIT B CIRCUIT C
SINGLE CIRCUIT
CIRCUIT A CIRCUIT B CIRCUIT C
SINGLE CIRCUIT
CIRCUIT A CIRCUIT B CIRCUIT C
SINGLE CIRCUIT
A 24
NONE 1.6 - - 1.6 15 - - 15 1.6 - - 1.6 15 - - 15
005H-XX 26.6 - - 26.6 30 - - 30 23.3 - - 23.3 25 - - 25
008H-XX 41.2 - - 41.2 45 - - 45 35.9 - - 35.9 40 - - 40
010H-XX 51.6 - - 51.6 60 - - 60 45.0 - - 45.0 45 - - 45
009Q-XX - - - 28.7 - - - 30 - - - 18.8 - - - 30
B 24
NONE 1.6 - - 1.6 15 - - 15 1.6 - - 1.6 15 - - 15
005H-XX 26.6 - - 26.6 30 - - 30 23.3 - - 23.3 25 - - 25
008H-XX 41.2 - - 41.2 45 - - 45 35.9 - - 35.9 40 - - 40
010H-XX 51.6 - - 51.6 60 - - 60 45.0 - - 45.0 45 - - 45
009Q-XX - - - 28.7 - - - 30 - - - 18.8 - - - 30
A 30
NONE 3.1 - - 3.1 15 - - 15 3.1 - - 3.1 15 - - 15
005H-XX 28.1 - - 28.1 30 - - 30 24.8 - - 24.8 25 - - 25
008H-XX 42.7 - - 42.7 45 - - 45 37.4 - - 37.4 40 - - 40
010H-XX 53.1 - - 53.1 60 - - 60 46.5 - - 46.5 50 - - 50
015H-XX 53.1 25.0 - 65.6 60 30 - 80 46.5 21.7 - 68.1 50 25 - 70
009Q-XX - - - 30.2 - - - 35 - - - 26.6 - - - 30
015Q-XX - - - 46.4 - - - 50 - - - 40.6 - - - 45
B 30/36
NONE 2.6 - - 2.6 15 - - 15 2.6 - - 2.6 15 - - 15
005H-XX 27.6 - - 27.6 30 - - 30 24.3 - - 24.3 25 - - 25
008H-XX 42.2 - - 42.2 45 - - 45 36.9 - - 36.9 40 - - 40
010H-XX 52.6 - - 52.6 60 - - 60 46.0 - - 46.0 50 - - 50
015H-XX 52.6 25.0 - 64.7 60 30 - 80 46.0 21.7 - 67.6 50 25 - 70
020H-XX 52.6 50.0 - 102.6 60 60 - 110 46.0 43.3 - 89.3 50 45 - 90
009Q-XX - - - 29.7 - - - 30 - - - 26.1 - - - 30
015Q-XX - - - 45.9 - - - 50 - - - 40.2 - - - 45
B 42/48
NONE 3.1 - - 3.1 15 - - 15 3.1 - - 3.1 15 - - 15
005H-XX 28.1 - - 28.1 30 - - 30 24.8 - - 24.8 25 - - 25
008H-XX 42.7 - - 42.7 45 - - 45 37.4 - - 37.4 40 - - 40
010H-XX 53.1 - - 53.1 60 - - 60 46.5 - - 46.5 50 - - 50
015H-XX 53.1 25.0 - 65.6 60 30 - 80 46.5 21.7 - 68.1 50 25 - 70
020H-XX 53.1 50.0 - 103.1 60 60 - 110 46.5 43.3 - 89.8 50 45 - 90
009Q-XX - - - 30.2 - - - 35 - - - 26.6 - - - 30
015Q-XX - - - 46.4 - - - 50 - - - 40.7 - - - 45
C 48
NONE 5.4 - - 5.4 15 - - 15 5.4 - - 5.4 15 - - 15
005H-XX 30.4 - - 30.4 35 - - 35 27.0 - - 27.0 30 - - 30
008H-XX 45.0 - - 45.0 45 - - 45 39.7 - - 39.7 40 - - 40
010H-XX 55.4 - - 55.4 60 - - 60 48.7 - - 48.7 50 - - 50
015H-XX 55.4 25.0 - 80.4 60 30 - 90 48.7 21.7 - 70.4 50 25 - 80
020H-XX 55.4 50.0 - 105.4 60 60 - 110 48.7 43.3 - 92.0 50 45 - 100
024H-XX 55.4 50.0 25.0 130.4 60 60 60 150 48.7 43.3 21.7 113.7 50 45 45 125
029H-XX 55.4 50.0 50.0 155.4 60 60 60 175 48.7 43.3 43.3 135.4 50 45 45 150
009Q-XX - - - 32.4 - - - 35 - - - 28.8 - - - 30
015Q-XX - - - 48.7 - - - 50 - - - 42.9 - - - 45
C 60
NONE 6.3 - - 6.3 15 - - 15 6.8 - - 6.8 15 - - 15
005H-XX 31.3 - - 31.3 35 - - 35 28.4 - - 28.4 30 - - 30
008H-XX 45.8 - - 45.8 50 - - 50 41.1 - - 41.1 45 - - 45
010H-XX 56.3 - - 56.3 60 - - 60 50.1 - - 50.1 60 - - 60
015H-XX 56.3 25.0 - 81.3 60 30 - 90 50.1 21.7 - 71.8 60 25 - 80
020H-XX 56.3 50.0 - 106.3 60 60 - 110 50.1 43.3 - 93.4 60 45 - 100
024H-XX 56.3 50.0 25.0 131.3 60 60 30 150 50.1 43.3 21.7 115.1 60 45 25 125
029H-XX 56.3 50.0 50.0 156.3 60 60 60 175 50.1 43.3 43.3 136.8 60 45 45 150
009Q-XX - - - 33.3 - - - 35 - - - 30.2 - - - 35
015Q-XX - - - 49.6 - - - 50 - - - 44.3 - - - 45
