160 MBOX ® STUDIO USER MANUAL
* These elements require additional input files in order to obtain the desired result. Users will need to provide their own additional
files.
** The modifier channels for the Damping effects apply damping in 1/30 sec. increments. Therefore, a value of 30 will add 1 sec-
ond to any change of that parameter. The damping is divided equally between the start and end of the movement curve. Effect
parameters can be adjusted during a move to affect only one side of the curve.
Notes for Effects:
1
These effects require that the second effect channel on the corresponding layer be set to 255. At that point, Mod 2A controls X-
position and Mod 2B controls Y-position. The default value for both additional controls is 127.
2
Effects 201-217 are not available for use on the Master fixture.
217 Spin
controls spin speed and direction
about X/Y/Z axes
Control 1 - Z Axis :
0 = stop + return to 0°
1 - 126 = fast to slow forwards
127 = stop
128 - 255 = slow to fast backwards
Control 2 - X Axis :
0 = stop + return to 0°
1 - 126 = fast to slow forwards
127 = stop
128 - 255 = slow to fast backwards
Control 3 - Y Axis :
0 = stop + return to 0°
1 - 126 = fast to slow forwards
127 = stop
128 - 255 = slow to fast backwards
Control 4 - N/A
Effects (Continued)
Refer to notes at end of Effects table.
ID Effect Description Control 1 Control 2
