156 MBOX ® STUDIO USER MANUAL
Play Mode
Values Play Mode
0 Forward Loop
1 Forward Loop, Pause when Layer Opacity = 0
2
Forward Loop, Pause and Reset to In-Point
when Layer Opacity = 0
10 Reverse Loop
11 Reverse Loop, Pause when Layer Opacity = 0
12
Reverse Loop, Pause and Reset to In-Point
when Layer Opacity = 0
20 Forward Once
21 Forward Once, Pause when Layer Opacity = 0
22
Forward Once, Pause and Reset to In-Point
when Layer Opacity = 0
30 Reverse Once
31 Reverse Once, Pause when Layer Opacity = 0
32
Reverse Once, Pause and Reset to In-Point
when Layer Opacity = 0
40-49 Forward Bounce
50-59 Reverse Bounce
60-69 Random
80-89 Scrub - In Frame
90-99 Scrub - Out Frame
130-134 Timecode Sync (Strict Lock)
135 Timecode Sync then Freewheel
136 Timecode Jam Sync
140 - 149 Layer Slave
150 - 159 Layer Master - Forward Loop
160 - 169 Layer Master - Forward Once
180
Kiosk Mode Non-Looping, pause on last
frame of last file
181 Kiosk Mode Non-Looping -loop last file
182 Kiosk Mode Non-Looping - fade out last file
185 - 189 Kiosk Mode Looping
190 - 199 SMPTE Kiosk Mode
250-255 Restart Movie from In Point
Sync Stream
Values Mode
0 Layer to Layer Stream (default)
1-2 Stream Number
Frame Blending
Values Description
0 No Frame Blending (more accurately, blend time = 0)
1-255
Variable Frame Blend Time, as a proportion of the
frame time. This is a square-law control, and 50%
blend time is achieved at value 210, 25% blend time
at value 165.
Video Input and Utility (Texture Folder 255)
Texture
Value
Input
0 Patch Info Display
121 Layer Copy FX+ Layer 1
122 Layer Copy FX+ Layer 2
123 Layer Copy FX+ Layer 3
124 Layer Copy FX+ Layer 4
125 Layer Copy FX+ Layer 5
126 Layer Copy FX+ Layer 6
127 Layer Copy FX+ Layer 7
128 Layer Copy FX+ Layer 8
240 CG Color bars
254 Video Input 2
255 Video Input 1
