Special commands require that the parameter value be held
for three seconds, followed by an immediate change to
value 0 (without any other values in between).
Master
Chan
Size
Function
Default
Snap
1
1
Pixel Map Level
255
N
2
1
0
Y
3
1
Texture Effect 1
0
Y
4
1
Modifier 1a
0
N
5
1
Modifier 1b
0
N
6
1
Red
255
N
7
1
Green
255
N
8
1
Blue
255
N
9
1
Intensity
255
N
10
1
0
Y
11
1
Master Audio Volume
255
N
Pixel Map Control
Values
Command
0
Enable All
254
Disable Masked
255
Disable All
Master Control Channel
Values
Command
0
None/Idle
10-19
Version HUD
20-29
Performance HUD
40-49
Master/Keystone/Shutter HUD
50-59
Layer HUD 1
60-69
Layer HUD 2
70-71
Raw Art-Net HUD
80-84
Show pix-map context view
85-89
Show pix-map fixture view
100 - 109
Show pix-map sample areas
110-111
Timecode HUD Center
112-113
Timecode HUD Top Right
114-115
Timecode HUD Top Left
116-117
Timecode HUD Bottom Right
118-119
Timecode HUD Bottom Left
120
Show Alignment Rectangles No Group,
No X or O
121
Show Alignment Rectangles Group 1, No X or O
122
Show Alignment Rectangles Group 2, No X or O
123
Show Alignment Rectangles Group 3, No X or O
124
Show Alignment Rectangles Group 4, No X or O
125
Show Alignment Rectangles Group 5, No X or O
126
Show Alignment Rectangles Group 6, No X or O
127
Show Alignment Rectangles Group 7, No X or O
128
Show Alignment Rectangles Group 8, No X or O
129
Show Alignment Rectangles Group 9, No X or O
130
Show Alignment Rectangles Group, No X and O
131
Show Alignment Rectangles Group 1, X and O
132
Show Alignment Rectangles Group 2, X and O
133
Show Alignment Rectangles Group 3, X and O
134
Show Alignment Rectangles Group 4, X and O
135
Show Alignment Rectangles Group 5, X and O
136
Show Alignment Rectangles Group 6, X and O
137
Show Alignment Rectangles Group 7, X and O
138
Show Alignment Rectangles Group 8, X and O
139
Show Alignment Rectangles Group 9, X and O
220
Cancel keyboard HUD *
230
File Sharing On *
231
File Sharing Off *
232
ARD On *
233
ARD Off *
240
Rescan Media Library *
250
Quit Mbox Application *
251
Shutdown Computer *
252
Restart Computer *
253
Restart Mbox Application *
Master Control Channel (Continued)
Values
Command
