5
50XCA06
Q
P
O
N Q
50XCA08,12,14
Q
N
P
N
O
Q
RIGHT VIEW
TOP VIEW
REAR VIEW
EVAP ACCESS
TOP VIEW
PANEL
CONDENSER
ACCESS
PANEL
INDOOR SUPPLY
AIR FLOW
R
G
F
K
J
H R
U
M
A
I
T
S
U
L
FRONT VIEW
CONTROL BOX
DISCONNECT
(OPT)
AIR FLOW
(BOTH SIDES)
OUTDOOR RTN
AIR FLOW
FILTER ACCESS
INDOOR RTN
CONDENSER
DISCHARGE
COND VFD
(OPT)
C
B
E
D
6.4 (1"-2" FLTR)
1.8
5.9
14.3
3/4" FPT DRAIN
NOTE: Dimensions are in inches.
UNIT
50XCA
WIDTH HEIGHT DEPTH
COND
SECTION
EVAP
SECTION
EVAP RETURN
DUCT
EVAP RETURN
DUCT
EVAP SUPPLY DUCT
(Blower Opening)
COND DISCHARGE
DUCT (Blower Opening)
A B C D E F G H I J K L M N O P Q R S T U
06 53.1 77.1 30.0 46.6 31.0 47.2 24.8 49.8 4.8 46 29.4 0.9 4.8 13.4 12.8 2.7 19.8 13.4 12.8 32.1 7.6
08 53.1 77.1 30.0 46.6 31.0 47.2 24.8 49.8 4.8 46 29.4 0.9 4.8 13.4 12.8 2.7 7.6 13.4 12.8 32.1 7.6
12 68.0 90.1 31.2 54.5 35.5 61.1 31.8 56.7 5.5 60 32.8 1.5 5.7 12.5 13.8 8.5 13.6 16.4 16.2 36.5 11.5
14 88.0 90.1 31.2 54.5 35.5 81.0 31.8 56.7 2.5 80 32.8 1.5 5.7 12.5 13.8 8.9 23.6 18.9 16.2 36.6 17.2
a50-8501
Dimensions — 50XCA06-14
