Typical piping and wiring – Carrier OMNIZONE 50XCA06-24 User Manual
Page 31
31
LEGEND
NOTES:
1. Wiring and piping shown are general points of connection guides only
and are not intended for or to include all details for a specific installation.
2. All wiring must comply with applicable local and national codes.
3. All piping must follow standard piping techniques. Refer to Carrier Sys-
tem Design Manual Part 3 for details.
4. Connect both drains to building waste system and provide a trap of suffi-
cient depth for unit static.
NEC
— National Electrical Code
Condenser Airflow
Evaporator Airflow
Power Wiring
Control Wiring
a50-8506
Typical piping and wiring
