EVAPORATOR FAN PERFORMANCE (cont)
LEGEND
Bhp — Brake Horsepower
ESP — External Static Pressure
NOTES:
1. Units are available with several motor hp options. Refer to the
physical data table.
2. Static pressure losses must be applied to external static pressure
before entering the fan performance table.
3. Interpolation is permitted; extrapolation is not.
4. Fan performance is based on filter, unit casing, and wet coil
losses.
50XCA24 (20 Tons)
CFM
ESP (in. wg)
0.00 0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
6,000 594 1.01 594 1.01 645 1.17 693 1.34 737 1.52 781 1.70 825 1.90 870 2.12 917 2.36 965 2.62
6,300 588 1.07 612 1.14 667 1.32 714 1.50 757 1.68 799 1.87 840 2.07 883 2.28 926 2.52 971 2.77
6,600 588 1.14 636 1.29 689 1.48 735 1.67 777 1.86 817 2.05 857 2.25 897 2.47 938 2.70 979 2.95
6,900 615 1.30 660 1.45 711 1.65 757 1.85 798 2.05 837 2.25 875 2.45 913 2.67 951 2.90 990 3.15
7,200 642 1.48 684 1.63 734 1.84 779 2.05 819 2.25 857 2.46 894 2.67 930 2.89 966 3.13 1003 3.37
7,500 668 1.68 708 1.83 756 2.04 801 2.26 840 2.47 877 2.69 913 2.91 948 3.13 983 3.37 1018 3.61
7,800 695 1.88 733 2.04 779 2.26 823 2.49 862 2.71 898 2.93 933 3.16 967 3.39 1000 3.63 1034 3.87
8,000 713 2.03 750 2.19 795 2.41 838 2.65 876 2.88 912 3.10 946 3.33 979 3.57 1012 3.81 1045 4.06
8,300 740 2.27 774 2.43 818 2.66 860 2.90 898 3.14 934 3.38 967 3.61 999 3.85 1031 4.10 1062 4.35
8,600 766 2.53 800 2.69 841 2.92 882 3.17 920 3.42 955 3.67 988 3.91 1019 4.16 1050 4.41 1081 4.67
8,900 793 2.80 825 2.97 865 3.20 905 3.46 942 3.72 977 3.97 1009 4.23 1040 4.48 1070 4.74 1100 5.00
9,200 820 3.09 850 3.27 888 3.50 928 3.77 964 4.04 998 4.30 1030 4.56 1061 4.82 1090 5.09 1119 5.36
9,500 846 3.40 876 3.58 912 3.82 950 4.09 987 4.37 1020 4.64 1052 4.92 1082 5.19 1111 5.46 1139 5.73
9,800 873 3.74 901 3.92 936 4.16 973 4.44 1009 4.72 1042 5.01 1074 5.29 1103 5.57 1131 5.85 1159 6.13
10,000 891 3.97 918 4.16 952 4.40 989 4.68 1024 4.97 1057 5.26 1088 5.55 1117 5.83 1145 6.12 1173 6.40
50XCA24 (20 Tons) (cont)
CFM
ESP (in. wg)
1.00 1.10 1.20 1.30 1.40 1.50 1.60 1.70 1.80 1.90
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
6,000 1014 2.90 1063 3.20 1112 3.53 1161 3.87 1208 4.23 — — — — — — — — — —
6,300 1016 3.05 1063 3.35 1110 3.66 1157 4.00 1204 4.36 1249 4.73 — — — — — — — —
6,600 1022 3.22 1066 3.51 1110 3.83 1155 4.16 1200 4.50 1245 4.87 1289 5.25 1332 5.65 — — — —
6,900 1030 3.42 1071 3.70 1113 4.01 1156 4.33 1199 4.67 1242 5.03 1285 5.41 1327 5.80 1369 6.21 1409 6.63
7,200 1041 3.64 1080 3.92 1119 4.22 1159 4.53 1200 4.87 1241 5.22 1282 5.59 1323 5.98 1364 6.38 1404 6.80
7,500 1053 3.88 1090 4.15 1127 4.45 1165 4.76 1203 5.09 1242 5.43 1282 5.80 1321 6.18 1361 6.58 1400 6.99
7,800 1067 4.14 1102 4.41 1137 4.70 1173 5.01 1209 5.33 1246 5.67 1284 6.03 1321 6.40 1360 6.80 1397 7.20
8,000 1078 4.32 1111 4.60 1145 4.88 1179 5.19 1214 5.51 1250 5.85 1286 6.20 1323 6.57 1360 6.96 1397 7.36
8,300 1094 4.62 1126 4.89 1158 5.18 1191 5.48 1224 5.80 1258 6.13 1292 6.48 1327 6.84 1362 7.22 1397 7.62
8,600 1111 4.93 1141 5.21 1172 5.50 1203 5.80 1235 6.11 1267 6.44 1300 6.78 1333 7.14 1366 7.51 1400 7.90
8,900 1129 5.27 1158 5.55 1188 5.84 1218 6.14 1248 6.45 1278 6.77 1309 7.11 1341 7.47 1372 7.83 1405 8.22
9,200 1147 5.63 1176 5.91 1204 6.20 1233 6.50 1262 6.81 1291 7.14 1320 7.47 1350 7.82 1381 8.19 1411 8.56
9,500 1167 6.01 1194 6.30 1222 6.59 1249 6.89 1277 7.20 1305 7.53 1333 7.86 1362 8.21 1391 8.57 1420 8.94
9,800 1186 6.41 1213 6.70 1240 7.00 1266 7.30 1293 7.62 1320 7.94 1347 8.28 1374 8.62 1402 8.98 1430 9.35
10,000 1200 6.69 1226 6.99 1252 7.29 1278 7.59 1304 7.91 1331 8.23 1357 8.57 1384 8.91 1411 9.27 1438 9.63
