EVAPORATOR FAN PERFORMANCE (cont )
LEGEND
Bhp — Brake Horsepower
ESP — External Static Pressure
NOTES:
1. Units are available with several motor hp options. Refer to the
physical data table.
2. Static pressure losses must be applied to external static pressure
before entering the fan performance table.
3. Interpolation is permitted; extrapolation is not.
4. Fan performance is based on filter, unit casing, and wet coil
losses.
50XCA16 (15 Tons)
CFM
ESP (in. wg)
0.00 0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
4500 594 0.50 594 0.50 603 0.51 656 0.59 706 0.67 753 0.75 798 0.82 840 0.90 880 0.98 — —
4750 588 0.53 588 0.53 624 0.58 676 0.67 724 0.75 770 0.83 813 0.91 855 1.00 894 1.08 933 1.16
5000 582 0.56 592 0.58 646 0.66 696 0.75 743 0.83 787 0.92 830 1.01 870 1.10 909 1.18 947 1.27
5250 576 0.59 616 0.66 668 0.75 716 0.84 762 0.93 805 1.02 847 1.11 886 1.20 924 1.29 961 1.39
5500 587 0.65 641 0.75 690 0.84 737 0.94 782 1.03 824 1.13 864 1.22 903 1.32 940 1.41 976 1.51
5750 614 0.75 665 0.85 713 0.94 759 1.04 802 1.14 843 1.24 882 1.34 920 1.44 957 1.54 992 1.64
6000 641 0.85 690 0.95 736 1.05 780 1.16 822 1.26 862 1.36 901 1.47 938 1.57 974 1.67 1008 1.78
6250 667 0.96 715 1.07 760 1.17 802 1.28 843 1.39 882 1.49 920 1.60 956 1.71 991 1.82 1025 1.93
6500 694 1.08 740 1.19 783 1.30 824 1.41 864 1.52 902 1.64 939 1.75 974 1.86 1009 1.97 1042 2.08
6750 721 1.21 765 1.32 807 1.44 847 1.56 885 1.67 923 1.79 958 1.90 993 2.02 1027 2.13 1059 2.25
7000 747 1.35 790 1.47 831 1.59 870 1.71 907 1.83 943 1.95 978 2.07 1012 2.19 1045 2.31 1077 2.43
7250 774 1.50 815 1.62 855 1.75 893 1.87 929 1.99 965 2.12 999 2.24 1032 2.37 1064 2.49 1096 2.62
7500 801 1.66 841 1.79 879 1.92 916 2.04 951 2.17 986 2.30 1019 2.43 1052 2.56 1084 2.69 1114 2.82
50XCA16 (15 Tons) (cont)
CFM
ESP (in. wg)
1.00 1.10 1.20 1.30 1.40 1.50 1.60 1.70 1.80 1.90
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
4500 — — — — — — — — — — — — — — — — — — — —
4750 — — — — — — — — — — — — — — — — — — — —
5000 983 1.36 — — — — — — — — — — — — — — — — — —
5250 997 1.48 1031 1.57 1064 1.67 — — — — — — — — — — — — — —
5500 1011 1.61 1045 1.70 1078 1.80 1109 1.90 — — — — — — — — — — — —
5750 1026 1.74 1059 1.84 1092 1.94 1123 2.05 1154 2.15 — — — — — — — — — —
6000 1042 1.88 1074 1.99 1106 2.10 1137 2.20 1167 2.31 1197 2.42 1226 2.53 — — — — — —
6250 1058 2.04 1090 2.15 1121 2.26 1152 2.37 1181 2.48 1210 2.59 1239 2.70 1267 2.81 — — — —
6500 1074 2.20 1106 2.31 1136 2.43 1166 2.54 1196 2.65 1225 2.77 1253 2.89 1280 3.00 1307 3.12 — —
6750 1091 2.37 1122 2.49 1152 2.60 1182 2.72 1211 2.84 1239 2.96 1267 3.08 1294 3.20 1321 3.32 1347 3.44
7000 1109 2.55 1139 2.67 1169 2.79 1198 2.92 1226 3.04 1254 3.16 1281 3.29 1308 3.41 1335 3.54 1360 3.66
7250 1126 2.74 1156 2.87 1186 2.99 1214 3.12 1242 3.25 1270 3.37 1297 3.50 1323 3.63 1349 3.76 1374 3.89
7500 1145 2.94 1174 3.07 1203 3.20 1231 3.33 1258 3.47 1286 3.60 1312 3.73 1338 3.86 1364 3.99 1389 4.13
