Physical data – Carrier OMNIZONE 50XCA06-24 User Manual
Page 4
4
LEGEND
UNIT 50XCA
06
08
12
14
16
24
NOMINAL CAPACITY (tons)
5
7
1
/
2
10
12
15
20
UNIT OPERATING WEIGHT (lb)
891
1144
1269
1298
1575
2000
COMPRESSOR
Copeland Scroll
Compressor Model
ZP57
ZP67
ZP51
ZP57
ZP72
ZP103
Qty
1
1
2
2
2
2
Steps of Control
1
1
2
2
2
2
Operating Charge R-410A (lb)
17.4
21.4
15.5 / 14.6
22.1 / 20.8
26.1 / 19.1
26.6 / 19.5
EVAPORATOR FAN
Adjustable, Belt-Drive, Centrifugal
Nominal Cfm
1750
2625
3500
4375
5250
7500
Cfm Range
1500 to 2500
2250 to 3750
3000 to 5000
3600 to 6000
4500 to 7500
6000 to 10000
Available Static (in. wg)
0 - 1.6
0 - 1.6
0 - 1.6
0 - 1.6
0 - 1.6
0 - 1.6
Evaporator Fan Size
110-10R
110-10R
120-9R
120-9R
120-9R
120-11R
Number of Evaporator Fans
1
2
2
2
3
3
Standard Speed Range (Rpm)
576 - 782
712 - 949
656 - 750
801 - 832
689 - 918
889 - 913
Max. Allowable Rpm
1600
1700
1700
1700
1700
1700
Belt Quantity ... Type
1...A50
1...BX42
1...BX48
1...BX46
1...BX48
1...BX56
Fan Pulley (Type)
AK89
BK65
BK70
BK100
BK67
BK67
Motor Pulley (Type)
1VP44
1VP34
1VP34
1VP56
1VP34
1VP44
Std HP
0.5
1
1
1.5
1.5
3
HP Range
0.5 - 1.5
1 - 2
1 - 3
1.5 - 5
1.5 - 5
3 - 7.5
Fan Shaft Size (in.)
0.75
1
1
1.1875
1.1875
1.1875
Motor Shaft Size (in.)
0.625
0.875
0.875
0.875
0.875
1.125
Center Distance (in.)
15.3
15.3
17.1
16.5
17.1
21.1
EVAPORATOR COIL
3
/
8
-in. OD, Enhanced Copper Tube, Aluminum Fins
Quantity Rows ... Fin/in.
4...12
4...12
5...12
5...12
5...12
5...12
Fin Block Size (H x L) (in.)
28 x 34
28 x 46
32 x 60
32 x 60
32 x 80
36 x 80
Face Area (sq ft)
6.6
8.9
13.3
13.3
17.8
20.0
RETURN AIR FILTERS (Std 1 in.,
throwaway)
(2) 25X25
(2) 25X25
(8) 16X16
(8) 16x16
(2) 16x20
(8) 16x16
(2) 16x20
(4) 18X18
(4) 18X24
CONDENSER FAN
Adjustable, Belt-Drive, Centrifugal
Nominal Cfm
2800
3500
6400
8000
8500
11400
Cfm Range
2100 - 3000
2625 - 4300
4800 - 7600
6000 - 9500
6375 - 9700
8550 - 12700
Available Static
0 - 1.0
0 - 1.0
0 - 1.0
0 - 1.0
0 - 1.0
0 - 1.0
Condenser Fan Size
110-10R
110-10R
150-12R
150-15R
150-15R
150-11R
Number of Condenser Fans
2
2
2
2
2
3
Standard Speed Range (Rpm)
656 - 875
712 - 949
712 - 949
764 - 1011
764 - 1011
820 - 1041
Max. Allowable Rpm
1700
1700
1700
1600
1600
1700
Belt Quantity ... Type
1...BX66
1...BX65
1...BX75
1...BX75
1...BX75
1...BX90
Fan Pulley (Type)
BK70
BK65
BK90
BK77
BK77
BK85
Motor Pulley (Type)
1VP34
1VP34
1VP34
1VP44
1VP44
1VP50
Std HP
1.0
1.5
2
2
3
5
HP Range
1 - 1.5
1 - 2
2 - 3
2 - 3
3 - 5
3 - 7.5
Fan Shaft Size (in.)
1
1
1
1.1875
1.1875
1.4375
Motor Shaft Size (in.)
0.875
0.875
0.875
1.125
1.125
1.125
Center Distance (in.)
26
26
29
29
29
35
CONDENSER COIL
3
/
8
-in. OD, Enhanced Copper Tube, Aluminum Fins
Quantity Rows ... Fin/in.
6...16
6...16
6...16
6...16
6...16
6...16
Fin Block Size (H x L)
30 x 46
30 x 46
34 x 60
34 x 80
34 x 80
40 x 80
Face Area (sq ft)
9.6
9.6
14.2
18.9
18.9
22.2
CONDENSATE DRAIN LINE (in.)
1 at
3
/
4
FPT
FPT — Female Pipe Thread
Physical data
