PRELIMINARY
CY14B104K, CY14B104M
Document #: 001-07103 Rev. *K
Page 21 of 31
Software Controlled STORE and RECALL Cycle
In the following table, the software controlled STORE and RECALL cycle parameters are listed.
Parameters
Description
20 ns
25 ns
45 ns
Unit
Min
Max
Min
Max
Min
Max
t
RC
STORE/RECALL Initiation Cycle Time
20
25
45
ns
t
SA
Address Setup Time
0
0
0
ns
t
CW
Clock Pulse Width
15
20
30
ns
t
HA
Address Hold Time
0
0
0
ns
t
RECALL
RECALL Duration
200
200
200
μs
t
SS
Soft Sequence Processing Time
100
100
100
μs
Switching Waveforms
Figure 13. CE and OE Controlled Software STORE and RECALL Cycle
Figure 14. Autostore Enable and Disable Cycle
t
RC
t
RC
t
SA
t
CW
t
CW
t
SA
t
HA
t
LZCE
t
HZCE
t
HA
t
HA
t
HA
t
DELAY
t
STORE
/t
RECALL
t
HHHD
t
LZHSB
High Impedance
Address #1
Address #6
Address
CE
OE
HSB (STORE only)
DQ (DATA)
RWI
t
RC
t
RC
t
SA
t
CW
t
CW
t
SA
t
HA
t
LZCE
t
HZCE
t
HA
t
HA
t
HA
t
DELAY
Address #1
Address #6
Address
CE
OE
DQ (DATA)
t
SS
Notes
28. The software sequence is clocked with CE controlled or OE controlled reads.
29. The six consecutive addresses must be read in the order listed in
Table 1
. WE must be HIGH during all six consecutive cycles.
30. This is the amount of time it takes to take action on a soft sequence command. Vcc power must remain HIGH to effectively register command.
31. Commands such as STORE and RECALL lock out IO until operation is complete which further increases this time. See the specific command.
