CY7C1012DV33

Document Number: 38-05610 Rev. *D

Page 5 of 11

AC Switching Characteristics

Over the Operating Range

[5]

Parameter

Description

–10

Unit

Min

Max

Read Cycle

t

power

[6]

V

CC

(Typical) to the First Access

100

μs

t

RC

Read Cycle Time

10

ns

t

AA

Address to Data Valid

10

ns

t

OHA

Data Hold from Address Change

3

ns

t

ACE

CE

Active LOW to Data Valid

[3]

10

ns

t

DOE

OE LOW to Data Valid

5

ns

t

LZOE

OE LOW to Low Z

[7]

1

ns

t

HZOE

OE HIGH to High Z

[7]

5

ns

t

LZCE

CE

Active LOW to Low Z

[3, 7]

3

ns

t

HZCE

CE Deselect

HIGH to High Z

[3, 7]

5

ns

t

PU

CE

Active LOW to Power Up

[3, 8]

0

ns

t

PD

CE Deselect

HIGH to Power Down

[3, 8]

10

ns

Write Cycle

[9, 10]

t

WC

Write Cycle Time

10

ns

t

SCE

CE

Active LOW to Write End

[3]

7

ns

t

AW

Address Setup to Write End

7

ns

t

HA

Address Hold from Write End

0

ns

t

SA

Address Setup to Write Start

0

ns

t

PWE

WE Pulse Width

7

ns

t

SD

Data Setup to Write End

5.5

ns

t

HD

Data Hold from Write End

0

ns

t

LZWE

WE HIGH to Low Z

[7]

3

ns

t

HZWE

WE LOW to High Z

[7]

5

ns

Notes

5. Test conditions assume signal transition time of 3 ns or less, timing reference levels of 1.5V, and input pulse levels of 0 to 3.0V. Test conditions for the read cycle use

output loading as shown in part a) of

Figure 2

, unless specified otherwise.

6. t

POWER

gives the minimum amount of time that the power supply is at typical V

CC

values until the first memory access is performed.

7. t

HZOE

, t

HZCE

, t

HZWE

, t

LZOE

, t

LZCE

, and t

LZWE

are specified with a load capacitance of 5 pF as in part (b) of

Figure 2

. Transition is measured

±200 mV from steady state

voltage.

8. These parameters are guaranteed by design and are not tested.
9. The internal write time of the memory is defined by the overlap of CE

1

or CE

2

or CE

3

LOW and WE LOW. Chip enables must be active and WE must be LOW to initiate

a write. The transition of any of these signals terminate the write. The input data setup and hold timing are referenced to the leading edge of the signal that terminates
the write.

10. The minimum write cycle time for Write Cycle No. 3 (WE controlled, OE LOW) is the sum of t

HZWE

and t

SD

.
