dIReCTIONS fOR USe
•Installing the side console for the
Relaxation Lounge
™
DIreCTIons for Use
7
5. Push the shelf to the left to lock on the hanger assembly.
slide
shelf
to
lock
notch
seat section
seat section
6. Insert Lock Chip in the gap on the left side as shown.
final
assembly
lock
chip
seat section
seat section
7. Feed the wires under the relaxation lounge and clip them into the
provided wire clips.
