100 VAC/20amps
1.5 amps
11.0 amps
24 VDC
330 watts
Class 1 Equipment
Type B Applied Part
IPX0
Continuous Operation @
10% Duty Cycle
15
M
A
IN
TE
N
A
N
C
E
MAINTENANCE
ELECTRICAL SPECIFICATIONS
Designed For: North America Europe Japan/Korea
Input Service
Current Draw
Maximum Monentary
Current Draw
Voltage Output
(control box)
Power Consumption
Electric Shock
Protection
Tabletop Applied Part
Table Top IEC 529
Rating
Mode of Operation
120 VAC/20amps
2.7 amps
9.0 amps
24 VDC
330 watts
Class 1 Equipment
Type B Applied Part
IPX0
Continuous Operation
@ 10% Duty Cycle
Storage &
Transport
Temperature: 32º - 100º F 0º-38º C Humidity: 60% relative humidity Pressure: no limitations known
During transport, DO NOT stack containers.
230 VAC/10amps
1.5 amps
5.0 amps
24 VDC
330 watts
Class 1 Equipment
Type B Applied Part
IPX0
Continuous Operation @
10% Duty Cycle
GENERAL CARE OF EQUIPMENT COMPONENTS
• Use only a mild solution of 4:1 diluted non-alcohol cleaner such as 409®, Fantastik® or some other non-abrasive
cleaner to wipe down the metal surfaces. Apply with a damp (not wet) lint-free cloth. Be sure excess liquid
does not drip onto, or into, any of the electrical controls or mechanisms. Be sure that the unit is unplugged
before cleaning these areas. Wipe these areas carefully with a lint free cloth.
• Electronic and or manual lift mechanisms require no general maintenance or lubrication.
• If the table will be out of use for an extended period of time, the power cord should be unplugged from the
receptacle. To prevent inadvertent damage to the plug or cord, the cable should be coiled and secured with a wire
tie or rubber band.
• It is important to visually inspect your tabe on a quarterly basis to ensure all components are working properly
and safely. Be sure to tighten all bolts to be sure they are secure. Over time they may work their way loose,
leading to an unsafe condition.
