STEP 1
Open your portable table on its side.
STEP 2
Remove the shiatsu cables or bolts to
enable your table to lay flat. There are
different types of shiatsu cables. Follow
the directions below based on the type
you have. Or follow your table
manufacturer’s instructions.
WING NUT
Remove the wing nut
Location of Shiatsu
release bolts or
wing nuts
Remove wood brace
Remove cable
Replace wood brace
and wing nut
Repeat these steps on both sides of the table. Locations shown above.
C-CLAMP
C-Clamp closed
Open C-Clamp
Remove Shiatsu
cable
Repeat these steps on both C-Clamps.
Close C-Clamp
CAUTION
LOADING YOUR PORTABLE TABLE
This is done every time you remove and replace your portable table. All the
adjustments to the base do not need to be done again.
Follow your table
manufacturer’s instructions
for using the Shiatsu option
if your table has them.
The instructions shown here
are for general reference
only.
