Microtel Series 1000EX - Manual (Page 5)

v
TABLE OF CONTENTS
INTRODUCTION 1
CHAPTER 1 -
DESCRIPTION OF THE SERIES 1000EX DIALER 3
CHAPTER 2 - INSTALLATION 11
Quick Start Procedure 19
CHAPTER 3 - OPERATION 23
Configuration 24
Basic System Information Overview 25
Basic System Information 26
Time And Date Setting 29
Automatic Call Outs 30
Telephone Numbers 30
Configuring Input/Output Modules 32
Operations 39
Alarm Acknowledgment 40
System Status 42
Site Control 44
Printer Operations 45
CHAPTER 4 - ADVANCED TOPICS 46
Advanced Setup 46
Adding and Removing I/O From Your System 46
Advanced Configuration Options 47
Advanced Phone Number Features 47
Advanced Operations 50
CHAPTER 5 - MAINTENANCE/TROUBLESHOOTING 52
APPENDICES 57
APPENDIX A: Technical Specifications 57
APPENDIX B: Glossary Of Dialer Terminology 61
APPENDIX C: Percent/Current/Voltage/Temperature Conversions 63
APPENDIX D: I/O Module Wiring Diagrams 65
APPENDIX E: Examples Of Fax Report 71
APPENDIX F: FCC Requirements 73
APPENDIX G: Series 1000EX Command Summary 75
APPENDIX H: Site Worksheet (Example and Blank) 77
LIST OF ILLUSTRATIONS
Figure 1: Controls and Indicators................................................................................ 2
Figure 2: Controls and Indicators................................................................................ 4
Figure 3: Power Supply Connection ...........................................................................11
Figure 4: Battery Connection ......................................................................................13
Figure 5: Phone Line and Local Handset Connection.................................................14
Figure 6: Communications RS-485 .............................................................................15
Figure 7: Terminal Connections Channels 1 thru 8 ....................................................16
Figure 8: Terminal Connections Channels 10 thru 25 and 26 thru 41 ........................17
