UG_1x66B_002 73M1866B/73M1966B GUI User Guide
Rev. 1.1 5
1 Introduction
The 73M1866B/73M1966B Graphical User Interface (GUI) provides control of the 73M1866B and
73M1966B registers. The GUI is used to configure the 73M1866B and 73M1966B demo boards and to
read the status conditions of these boards. This document applies to GUI software version 1.3.
The GUI can be use with either the Demo Board or the Keychain Board. The GUI cannot be used if the
SPI is connected to a host device. For example, if a Keychain Board is embedded in an application, use
the appropriate driver (MIPS, ARM, etc.) to configure the Keychain Board.
Install the GUI on a PC running Microsoft Windows
®
versions XP, Me or 2000. The installation requires
one megabyte of disk storage.
In this user guide, the 73M1866B and 73M1966B will be collectively referred to as the 73M1x66B.
The FPGA controls are not for customer use. Do not change the parameters on the FPGA tab.
Similarly, do not select FPGA Functions from the Controls menu or use the functions on the FPGA
Memory Functions screen.
