78M6610+LMU Evaluation Kit User Manual
4 Rev 1
1 Introduction
The 78M6610+LMU evaluation kit (EV kit) demonstrates the capability of the 78M6610+LMU for monitoring a
single-phase or split-phase AC load using up to two voltages and two currents (sensors included). The EV kit
connects to a PC through a USB cable that provides both power and data communication to the board. A
Windows®-based graphical user interface (GUI) communicates with the device over a virtual for simplified
access to measurement data and controls.
1.1 Ordering Information
PART TYPE
78M6610+LMUEVK1# Evaluation Kit
#Denotes a RoHS-compliant device that may include lead that is
exempt under the RoHS requirements.
1.2 Package Contents
The 78M6610+LMU EV kit includes the following:
• 78M6610+LMU Evaluation Board
• Two 20A Current Transformers
• USB Cable Assembly USB A-B 28/24 1.8M (Tyco/Amp 1487588-3)
• CD with Documentation, GUI Application, and USB Drivers
• Calibration Coefficients Document (Hardcopy Only)
1.3 System Requirements
In addition to an AC source and load for measuring, the EV kit requires a Windows PC with the following
features:
• 1GHz processor and 1GB RAM
• Minimum 1024 x 768 video display resolution
• Available USB port
• Microsoft Windows 7 or Windows XP®
Windows and Windows XP are registered trademarks of Microsoft Corp.
