6613_OMU_2+2S_URT_V1_00 Firmware Description Document UG_6613_060
44 Rev. 1.1
Voltage D4 SAG Voltage Alarm Threshold
D5 Min Voltage Alarm Threshold
D6 Max Voltage Alarm Threshold
Unused D7 Unused
Current - Outlet 1 D8 Reserved
D9 Max Current Alarm Threshold (WB)
Power Factor - Outlet 1 DA Reserved
DB Reserved
DC Power Factor Alarm - Threshold (WB)
DD Power Factor Alarm + Threshold (WB)
Current - Outlet 2 DE Reserved
DF Max Current Alarm Threshold (WB)
Power Factor - Outlet 2 E0 Reserved
E1 Reserved
E2 Power Factor Alarm - Threshold (WB)
E3 Power Factor Alarm + Threshold (WB)
Total Current E4 Reserved
E5 Max Current Alarm Threshold (WB)
Alarm Mask for Status Regs E6 Alarm Mask for Status
Alarm Mask for Alarm DI/O E7 Alarm Mask for Alarm DIO
Relay Controls F0 Relay On/Off Control
Min/Max Controls F1 Min/Max Controls
Clear Control F2 Accumulator and Counter Clear. Power Factor Polarity
